106 Dell EMC PowerEdge MX SmartFabric Configuration and Troubleshooting Guide
10.4.1.2 show fcoe sessions
The show fcoe sessions command shows active FCoE sessions. The output includes MAC addresses,
Ethernet interfaces, the FCoE VLAN ID, FC IDs, and WWPNs of logged-in CNAs.
Note: Due to the width of the command output, each line of output is shown on two lines below.
C140A1# show fcoe sessions
Enode MAC Enode Interface FCF MAC FCF interface VLAN
FCoE MAC FC-ID PORT WWPN PORT WWNN
--------------------------------------------------------------------------------
-------------------------------------------------------------------------
06:c3:f9:a4:cd:03 Eth 1/71/1 20:04:0f:00:ce:1d ~ 30
0e:fc:00:01:01:00 01:01:00 20:01:06:c3:f9:a4:cd:03 20:00:06:c3:f9:a4:cd:03
f4:e9:d4:73:d0:0c Eth 1/1/1 20:04:0f:00:ce:1d ~ 30
0e:fc:00:01:02:00 01:02:00 20:01:f4:e9:d4:73:d0:0c 20:00:f4:e9:d4:73:d0:0c
10.4.1.3 show vfabric
The show vfabric command output provides a variety of information including the default zone mode, the
active zone set, and interfaces that are members of the vfabric.
C140A1# show vfabric
Fabric Name New vfabric
Fabric Type FPORT
Fabric Id 1
Vlan Id 30
FC-MAP 0xEFC00
Vlan priority 3
FCF Priority 128
FKA-Adv-Period Enabled,8
Config-State ACTIVE
Oper-State UP
==========================================
Switch Config Parameters
==========================================
Domain ID 1
==========================================
Switch Zoning Parameters
==========================================
Default Zone Mode: Allow
Active ZoneSet: None
==========================================
Members
fibrechannel1/1/44:1
ethernet1/1/1
ethernet1/71/1
ethernet1/71/2
10.4.1.4 show fc switch
The show fc switch command verifies the switch mode (e.g. F_Port) for FC traffic.
