82 Appendix
www.dell.com | support.dell.com
Ports and Connectors
Video 15-hole connector
Audio microphone connector, stereo
headphone/speakers connector
USB (2) 4-pin USB 2.0-compliant connector
Modem RJ-11 port
Network adapter RJ-45 port
IEEE 1394 4-pin serial connector
S-video TV-out 7-pin mini-DIN connector
Mini PCI Type IIIA Mini PCI card slot
Secure Digital SD slot
Communications
Modem:
Type
v.92 56K MDC
Controller
softmodem
Interface
internal AC’97 bus
Network adapter 10/100 EthernetLAN on system board
Wireless internal Mini PCI Wi-Fi support
Video
Video type Intel UMA integrated
Video controller Intel 855GME integrated chip set
Video memory Digital Video Memory (DVM) technology;
up to 64-MB shared memory
LCD interface LVDS
TV support NTSC or PAL in S-video mode
