Using the AutoOn feature
This feature allows you to configure the days when the system has to turn on automatically from
hibernate or power off state at the time specified in AutoOnHour and AutoOnMinute.
NOTE: AutoOn capabilities work only for a system running on AC power. This feature does not work
if the system is running on battery power.
Select one of the following options:
• Disabled — To disable the AutoOn capabilities.
• Every Day — To enable the AutoOn capabilities for every day.
• WeekDays — To enable the AutoOn capabilities on weekdays (Monday to Friday).
• Select Days — To enable or disable the AutoOn capabilities on selected days. If you select this option,
the following attributes are available in the PowerManagement category:
– AutoOnMonday — To enable or disable the AutoOn capabilities on Mondays.
– AutoOnTuesday — To enable or disable the AutoOn capabilities on Tuesdays.
– AutoOnWednesday — To enable or disable the AutoOn capabilities on Wednesdays.
– AutoOnThursday — To enable or disable the AutoOn capabilities on Thursdays.
– AutoOnFriday — To enable or disable the AutoOn capabilities on Fridays.
– AutoOnSaturday — To enable or disable the AutoOn capabilities on Saturdays.
– AutoOnSunday — To enable or disable the AutoOn capabilities on Sundays.
You can enable or disable individual days by setting AutoOnSunday -enable, and AutoOnMonday -
disable, etc.
Configure AutoOnHour and AutoOnMinute attributes in order to set the time for the AutoOn function.
• AutoOnHour — To set the hour at which you want the system to turn on automatically, provide the
value ranging from 0-23. To set the time 11:59 p.m., provide the value as 23.
• AutoOnMinute — To set the minute at which you want the system to turn on automatically, provide
the value ranging from 0-59. To set the time 11:59 p.m., provide the value as 59.
Example: To turn on the system automatically on weekdays.
Command: Set-Item -Path DellSmbios:\PowerManagement\AutoOn "WeekDays"
Example: To turn on the system automatically on Fridays.
Command: Set-Item -Path DellSmbios:\PowerManagement\AutoOnFriday "Enabled"
Example: To turn on the system automatically on Sundays at 11:59 p.m..
Command: Set-Item -Path DellSmbios:\PowerManagement\AutoOnSunday "Enabled"
Set-Item -Path DellSmbios:\PowerManagement\AutoOnHour "23"
Set-Item -Path DellSmbios:\PowerManagement\AutoOnMinute "59"
Using the AdvanceBatteryChargeConfiguration feature
This feature allows you to configure AdvancedBatteryChargingMode and
AdvancedBatteryChargeConfiguration options in the PowerManagement category. Advanced Battery
charge mode uses a standard charging algorithm and other methods during nonworking hours to
maximize battery health. During working hours, ExpressCharge is used to charge the batteries faster. You
can configure the days and the Work Period during which you want the battery to charge.
