Reference Guide

--KbdBacklightTimeoutBatt
Valid Argument 5s, 10s, 15s, 30s, 1m, 5m, 15m, Never
Description
Congures the timeout value for the keyboard backlight when the system is running only on battery
power.
• 5s — Keyboard backlight stays on for 5 seconds.
• 10s — Keyboard backlight stays on for 10 seconds.
• 15s — Keyboard backlight stays on for 15 seconds.
• 30s — Keyboard backlight stays on for 30 seconds.
• 1m — Keyboard backlight stays on for 1 minute.
• 5m — Keyboard backlight stays on for 5 minutes.
• 15m — Keyboard backlight stays on for 15 minutes.
• Never — Keyboard backlight always stays on.
KeyboardBackLightColor
Description
Enables and congures supported colors on the keyboard backlight for the rugged systems. Also,
displays the active color and sets the color (RGB value) for CustomColor1 and CustomColor2.
Valid Argument
None
Suboptions
EnableColor, ActiveColor, CustomColor1, CustomColor2
Sub Options
The following are the sub options of keyboardbacklightcolor.
--EnableColor
Valid Argument
White, Red, Green, Blue, CustomColor1, CustomColor2, and None.
Description Displays or enables the supported colors on the keyboard backlight. Press Fn+C to switch among the
enabled colors.
NOTE: If 'none' is selected, keyboard backlight color switching using Fn+C key combination
will not be possible. The value 'none' cannot be combined with any other color.
Example
cctk KeyboardBackLightColor --EnableColor=Green,Blue,Red
EnableColor=Green,Blue,Red
--ActiveColor
Valid Argument
White, Red, Green, Blue, CustomColor1 and CustomColor2.
Description Displays or sets an active color for the keyboard backlight.
Example
cctk KeyBoardBacklightColor --ActiveColor=Green, White, Red, Blue
KeyBoardBacklightColor --ActiveColor=White, Red, Green, Blue
60 Dell Command | Congure options
