NOTE: The AddDevice option is not supported on the systems with UEFI-based BIOS.
Example
C:\>cctk --AddDevice=Usb
--AdiModeChannel1
Valid Argument Unused, AdcInput, DacOutput, DacAndAdc, Gpio
Description
Sets the dened Analog/Digital Interface mode for channel 1.
• Unused - Channel is unused.
• AdcInput - Sets the channel mode as Analog-to-Digital Converter (ADC) input.
• DacOutput - Sets the channel mode as Digital-to-Analog Converter (DAC) output.
• DacAndAdc - Sets the channel mode as DAC output, but can be monitored through ADC input.
• Gpio - Sets the channel mode as General Purpose Input or Output.
--AdiModeChannel2
Valid Argument Unused, AdcInput, DacOutput, DacAndAdc, Gpio
Description
Sets the dened Analog/Digital Interface mode for channel 2.
• Unused - Channel is unused.
• AdcInput - Sets the channel mode as Analog-to-Digital Converter (ADC) input.
• DacOutput - Sets the channel mode as Digital-to-Analog Converter (DAC) output.
• DacAndAdc - Sets the channel mode as DAC output, but can be monitored through ADC input.
• Gpio - Sets the channel mode as General Purpose Input or Output.
--AdiModeChannel3
Valid Argument
Unused, AdcInput, DacOutput, DacAndAdc, Gpio
Description
Sets the dened Analog/Digital Interface mode for channel 3.
• Unused - Channel is unused.
• AdcInput - Sets the channel mode as Analog-to-Digital Converter (ADC) input.
• DacOutput - Sets the channel mode as Digital-to-Analog Converter (DAC) output.
• DacAndAdc - Sets the channel mode as DAC output, but can be monitored through ADC input.
• Gpio - Sets the channel mode as General Purpose Input or Output.
--AdiModeChannel4
Valid Argument
Unused, AdcInput, DacOutput, DacAndAdc, Gpio
Description
Sets the dened Analog/Digital Interface mode for channel 4.
• Unused - Channel is unused.
• AdcInput - Sets the channel mode as Analog-to-Digital Converter (ADC) input.
• DacOutput - Sets the channel mode as Digital-to-Analog Converter (DAC) output.
