Reference Guide

• LanWlan — On systems that have onboard LAN and wireless LAN hardware, enables wake on
either wired or wireless LAN.
• LanWithPxeBoot — Enables the network controller and causes the system to wake up and
immediately boot to PXE when a wake packet is sent to the system in the S4 or S5 state.
• Sfp — Allows the system to wake-up by special SFP signals.
• LanSfp — Allows the system to wake-up either by LAN, or by SFP signals.
• SfpWithPxeBoot — Allows the system to wake-up by SFP singnals, and immediately boot to PXE.
Example
C:\>cctk --WakeOnLan=LanWithPxeBoot
WakeOnLan=LanWithPxeBoot
--WakeOnLan2
Valid Argument LanOnly, Disabled, LanWithPxeBoot
Description
Denes the wake-on-LAN2 feature.
• LanOnly — The system wake-on-LAN feature is enabled; either an onboard or an add-in NIC can
wake the system up.
• Disabled — The system does not respond to magic packets or other means of wake-on-LAN. The
NIC chip section that looks for packets will not be powered.
• LanWithPxeBoot — Enables the network controller and causes the system to wake up and
immediately boot to PXE when a wake packet is sent to the system in the S4 or S5 state.
Example
C:\>cctk --WakeOnLan2=LanWithPxeBoot
WakeOnLan2=LanWithPxeBoot
--WakeOnLanBootOvrd
Valid Argument
Enabled, Disabled
Description
Enables or disables the wake on LAN boot override feature.
• Enabled — When the system powers on due to a wake-on-LAN event, the NIC boot-ROM is
automatically given the highest boot priority, pre-pending the PXE boot-ROM to the system current
boot sequence. If the system powers on due to some other event, this selection does not inuence
the boot sequence.
• Disabled — Disables the boot override feature and the system boot sequence is in eect for all
types of system power on.
--WarningsAndErr
Valid Argument
PromptWrnErr, ContWrn, ContWrnErr
Description During POST the system continues to boot or pauses when warnings or errors are detected. This
feature can be used for the remotely managed systems that do not have a keyboard or a console for
the user to respond.
• PromptWrnErr — System pauses for the user to respond when warnings or errors are detected.
• ContWrn — System continues to boot when warnings are detected, but pauses for the user to
respond when errors are detected.
• ContWrnErr — System continues to boot when warnings or errors are detected.
Dell Command | Congure options 109
