Dell Chassis Management Controller Version 6.0 for PowerEdge M1000e RACADM CLI Guide September 2017 Rev.
Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Contents Chapter 1: Introduction................................................................................................................. 7 New in this release.............................................................................................................................................................. 7 Supported RACADM Interfaces.......................................................................................................................................
getmodinfo..........................................................................................................................................................................54 getniccfg............................................................................................................................................................................. 56 getpbinfo......................................................................................................................................
idRacProductInfo (Read Only)................................................................................................................................. 97 idRacDescriptionInfo (Read Only)........................................................................................................................... 97 idRacVersionInfo (Read Only).................................................................................................................................. 97 idRacBuildInfo (Read Only)....
cfgCurrentIPv6LanNetworking (Read Only)............................................................................................................. 151 cfgNetTuning....................................................................................................................................................................153 cfgRacSecurity.................................................................................................................................................................
1 Introduction NOTE: In this version of RACADM, the Linux shell features such as ctrl+d, home, del, and end shortcut keys are not supported. This document provides information about the RACADM subcommands, supported RACADM interfaces, and property database groups and object definitions for Dell Chassis System (CMC).
SSH, Telnet, or Remote RACADM racadm -r -u username -p password racadm -r -u username -p password getconfig -g -o
Table 1. RACADM Command Options (continued) Option Description -p Specifies the password used to authenticate the command transaction. If the -p option is used, the -i option is not allowed. --nocertwarn Does not display certificate related warning message. -i Specifies the index number for the indexed group, if applicable. -g Specifies the group name if applicable. -o Specifies the object name if applicable.
Subcommand CMC Telnet/SSH/Serial Remote RACADM getioinfo Yes Yes getkvminfo Yes Yes getled Yes Yes getmacaddress Yes Yes getmodinfo Yes Yes getniccfg Yes Yes getpbinfo Yes Yes getpminfo Yes Yes getraclog Yes Yes getractime Yes Yes getredundancymode Yes Yes getsel Yes Yes getsensorinfo Yes Yes getslotname Yes Yes getssninfo Yes Yes getsvctag Yes Yes getsysinfo Yes Yes gettracelog Yes Yes getversion Yes Yes help and help subcommand Yes Yes ifconfi
Subcommand CMC Telnet/SSH/Serial Remote RACADM setractime Yes Yes setslotname Yes Yes setsysinfo Yes Yes sshpkauth Yes Yes sslcertdownload No Yes sslcertupload No Yes sslcertview Yes Yes sslcsrgen Yes Yes sslresetcfg Yes Yes testemail Yes Yes testfeature Yes Yes testtrap Yes Yes traceroute Yes Yes traceroute6 Yes Yes Other Documents You May Need In addition to this guide, you can access the following guides available on the Dell Support website at www.dell.
NOTE: Warranty information may be included within this document or as a separate document. Accessing support content from the Dell EMC support site Access supporting content related to an array of systems management tools using direct links, going to the Dell EMC support site, or using a search engine. ● Direct links: ○ For Dell EMC Enterprise Systems Management and Dell EMC Remote Enterprise Systems Management—https:// www.dell.com/esmmanuals ○ For Dell EMC Virtualization Solutions—https://www.dell.
2 RACADM Subcommand Details This section provides detailed description of the RACADM subcommands including the syntax and valid entries.
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • krbkeytabupload netstat ping ping6 racdump racreset racresetcfg remoteimage set serveraction setarraycfg setassettag setchassisname setflexaddr setled setniccfg setractime setslotname setsysinfo sshpkauth sslcertdownload sslcertupload sslcertview sslcsrgen sslresetcfg testemail testfeature testtrap traceroute traceroute6 Guidelines to Quote Strings Containing Special Characters When Using RACADM Commands When using strings that contain special ch
● " (double quotation mark) ● ` (back quotation mark) Racadm help and help with subcommand Description Displays all the subcommands you can use with the RACADM command and a one-line description about each subcommand. ? followed by displays the syntax for the specified command. To use this subcommand, you must have the CMC Login User privilege. You can also use the help and help commands to obtain the same information.
getsel getsensorinfo getslotname getssninfo getsvctag getsysinfo gettracelog getversion getarraycfg ifconfig jobqueue krbkeytabupload netstat ping ping6 racdump racreset racresetcfg remoteimage serveraction set setassettag setchassisname setflexaddr basis.
Table 2. help and help subcommand (continued) Synopsis ● ● ● ● Input ● — specifies the subcommand for which you need the help information. ● — specifies the device name such as iDRAC, BIOS, NIC, LifecycleController, FC, system, or Storage. ● — specifies the group name supported by the corresponding device. ●
—switch- where n=1–6 —kvm ● — Action that you want to run on the specified module. Values are: ● —powerdown — (Chassis only) Powers down the chassis. —powerup — (Chassis only) Powers up the chassis. —powercycle — Power cycles the module. NOTE: If a server takes longer duration to turn off gracefully after the chassis power cycle is initiated, CMC stops functioning indicating that graceful shutdown of the server was unsuccessful.
○ Enable the quick deploy parameter in CMC DNS Settings racadm deploy -q -e 1 ○ Update quick deploy parameters racadm deploy -q --qd ● clear — Clear chassis log ○ To clear chassis log racadm chassislog clear NOTE: To clear the chassis log, you must have the Clear Logs Administrator privilege. NOTE: racadm chassislog export -f is supported only for remote interfaces. closessn Description Closes a communication session on the device.
Synopsis Input racadm clrraclog N/A clrsel Description Removes all the existing records from the System Event Log (SEL). To use this subcommand, you must have Clear Logs permission.
Synopsis ● racadm config -g -o
The mycmc.cfg file may be created from the getconfig command. This file may also be edited manually using the parsing rules. NOTE: The mycmc.cfg file does not contain passwords. To include passwords in the file, you must enter them manually.
NOTE: Use setniccfg to configure static IP address, subnet mask, and gateway, and DHCP, speed and duplex properties. Synopsis ● racadm deploy -m server- -u root -p -s -b -o no | yes ● racadm deploy -m server- -u root -p -s -b -o no | yes -6 where must be a number between 0 and 128.
NOTE: The -q option must be specified with the -n option. ● -e — Uses the CMC DNS settings for quick deploy. The legal values are: ○ 1 — Enable ○ 0 — Disable ● --qd — Updates the quick deploy parameters to the servers. This option works only with the -q option. Output None Example ● Set root password, configure static IPV4 address, set first boot device to HDD, and enable boot once for server-1. racadm deploy -m server-1 -u root -p -s 192.168.0.20 255.255.255.0 192.168.0.
Table 3. eventfilters (continued) NOTE: The general format of an alert descriptor: cmc.alert.category.[subcategory].[severity] where, category is mandatory, but subcategory and severity are optional. A severity cannot precede a subcategory. Valid category values are: ● ● ● ● ● All System Updates Audit Config Valid severity values are: ● Critical ● Warning ● Informational Valid examples of alert descriptors are: ● cmc.alert.all ● cmc.alert.audit ● cmc.alert.audit.lic ● cmc.alert.audit.
Table 3. eventfilters (continued) ● Display eventfilter configurations for a specific severity and subcategory. For example, a severity of warning in the subcategory licensing under audit category: racadm eventfilters get -c cmc.alert.audit.lic.warning ● Clear all available alert settings: racadm eventfilters set -c cmc.alert.all -n none ● Configure using severity as a parameter.
CAUTION: Using the -r switch deactivates the extended storage feature, if active; reformats the SD card in the active CMC card slot; and may Restart the active CMC. -c — — must be one of the following: ● flexAddress ● flexAddressPlus ● ExtendedStorage (with -d, or -r) NOTE: The —a option is not supported for CMC 5.0.
FlexAddressPlus: The feature is bound to this chassis ExtendedStorage: The feature is bound to this chassis fwupdate Table 4. fwupdate — Details Description Allows you to update the firmware on the KVM, active CMC, standby CMC, iDRAC or an IOM infrastructure device. You can: ● Check the firmware update process status. ● Update CMC from FTP or TFTP server by providing an IP address and optional path. ● Update CMC from the local file system using Remote RACADM.
Table 4. fwupdate — Details (continued) Synopsis For SSH or Telnet or Serial: racadm fwupdate -g -u -a -d [-m ] racadm fwupdate -f -d [-m ] racadm fwupdate -u -m iominf- racadm fwupdate -s [-m ] racadm fwupdate -c [-m ] For Remote RACADM: racadm fwupdate -p -u -d [-m ] racadm fwupdate -g -u -a 192.168.0.10 -d firmimg.
Table 4. fwupdate — Details (continued) ● -p — The -p option is used to upload the firmware image from the client. NOTE: This option is only supported on the remote interface(s) and Windows operating systems. ● -m — Specifies the module or device to be updated. is one of the following values: ○ cmc-active — default state if –m is not specified.
Table 4. fwupdate — Details (continued) ● Update firmware on servers of iDRAC generation. racadm fwupdate -g -u -a 192.168.0.2 -d firmimg.imc -m server-iDRAC ● Update firmware on multiple IOM infrastructure devices. racadm fwupdate -u -m iominf-4 -m iominf-5 -m iominf-6 ● Query the status of all firmware targets to be updated. racadm fwupdate -s -m all ● Query the current status of the firmware update process for a particular module.
NOTE: If CMC is not in the network, you cannot export the chassis configuration profile to a remote network share with proxy using the get command. But, you can export the chassis configuration profile to the local management station.
● critical ● warning ● info -m — Specifies the module for which the messages such as critical, noncritical (warning), and informational are displayed. The command racadm getactiveerrors displays critical, noncritical (warning), and informational messages for the selected module. When used with -s option, only selected message type for the module is displayed.
● The error message displayed for invalid syntax. racadm getactiveerrors –z cmc-1 ERROR: The syntax of the command specified is not correct. ● The error message displayed for invalid parameter. racadm getactiveerrors –m server-80 ERROR: The syntax of the command specified is not correct. ● To display entire information log. racadm getactiveerrors -s info Module ID = 1 Severity = Critical Message = A fabric mismatch deteceted for mezzanine card B1.
getassettag Description Displays the asset tag for the chassis. To run this subcommand, you must have the CMC Login User privilege. Synopsis Input racadm getassettag [-m ] -m — Specifies the module whose asset tag you want to view. Legal value: chassis Example ● Display asset tag for chassis racadm getassettag -m chassis ● racadm getassettag chassis 78373839–33 getchassisname Description Displays the name of the chassis.
● -g — The -g or group option, is used to display the configuration for a single group. The is the name for the group used in the racadm.cfg files. If the group is an indexed group, then use the-i option. ● -h — The -h or help option, displays a list of all available configuration groups in alphabetical order. This option is useful when you do not remember exact group names. ● -i — The -i or index option, is valid only for indexed groups and is used to specify a unique group.
If you do not configure the following key attributes in their respective groups for a particular index, the groups are not saved in to the file. This is applicable for all the index groups. Saves all group configuration objects from CMC to myrac.cfg. racadm getconfig -f myrac.cfg Saves all group configuration objects from CMC to myrac.cfg. racadm getconfig -f myrac.
getdcinfo Description Displays general I/O module and daughter card configuration information. Only the CMC controls daughter cards. To run this subcommand, you must have the CMC Login User privilege. NOTE: Fabric verification for server DCs is performed only when the chassis is turned on. When the chassis is on standby power, iDRACs on the server modules remain turned off and thus are unable to report the server's DC fabric type.
server-3 Not Present None N/A None N/A server-4 Present None N/A Gigabit Ethernet OK server-5 Not Present None N/A None N/A server-6 Not Present None N/A None N/A server-7 Not Present None N/A None N/A server-8 Present FibreChanne l 4 Invalid None N/A server-9 Extension(1 ) None N/A None N/A server-10 Not Present None N/A None N/A server-11 Not Present None N/A None N/A server-12 Not Present None N/A None N/A server-13 Not Present None N/A None
server-4 Present None Broadcom M5708t server-5 Not Present None None server-6 Not Present None None server-7 Not Present None None server-8 Present LPe1105-M4 None server-9 Extension(1) None None server-10 Not Present None None server-11 Not Present None None server-12 Not Present None None server-13 Not Present None None server-14 Not Present None None server-15 Not Present None None server-16 Not Present None None getflexaddr Description Displays enable
Synopsis racadm getflexaddr [-i ] Input -i — Specifies the slot information that must be displayed. can be from 1 to 16. Output None Example Display current flexaddress settings for all slots and fabrics.
16 Enabled Not Present A Gigabit Ethernet Enabled B None Enabled C None Enabled Display the current flexaddress setting for slot 9.
Synopsis racadm getfanreqinfo Input N/A Output None Example racadm getfanreqinfo [Ambient Temperature Fan Request %] 38 [Server Module Fan Request Table] 1 SLOT-01 N/A N/A Not Present N/A 2 WINJGKC47ACGKG PowerEdge M630 ON Present 38 3 WINN24BRAT3L1J PowerEdge M630 ON Present 38 4 SLOT-04 PowerEdge M630 ON Present 17 5a nodea.NOBLEEST .
9 SLOT-9 N/A Present 0 10 SLOT-10 N/A Present 0 11 SLOT-11 ON Present 38 12 SLOT-12 N/A Extension(4) N/A N/A 13 SLOT-13 N/A Extension(5) N/A N/A 14 SLOT-14 N/A Extension(6) N/A N/A 15 SLOT-15 PowerEdge M630 ON Present 38 16 SLOT-16 N/A N/A Present N/A Switch Module Fan Request Table Switch-1 PowerEdge M I/O Aggregator 10 GbE KR Present 30 Switch-2 PowerEdge M I/O Aggregator 10 GbE KR Present 30 Switch-3
NOTE: The fabric type may be any supported I/O fabric type, such as Ethernet, Fibre Channel, and InfiniBand. Synopsis Input ● racadm getioinfo [-m ] [-s] ● racadm getioinfo -o ● racadm getioinfo -m switch- -o ● -m — Specifies the module or device. must be switch — , where n = 1–6 ● -s — Displays stack information. ● -o — Displays IOA Flex module information.
● ● ● 46 racadm getioinfo -s abc1234 Switch -1 A1 Present Master N/A N/A abc1234 Switch -2 A2 Present Standalone 1 N/A abc1234 Switch -3 B1 Present Master N/A N/A abc1234 Switch -4 B2 Present Master N/A N/A abc1234 Switch -5 C1 Present Standalone 0 N/A abc1234 Switch -6 C2 Present Master N/A N/A racadm getioinfo -m switch-1
● Switch-5 Optional Module 1 Optional Module 2 4x10G Base-T FlexIO Module FlexIO Module Absent Switch-6 Optional Module 1 Optional Module 2 N/A N/A racadm getioinfo -m switch-4 -o Switch-4 Optional Module 1 Optional Module 2 N/A N/A getkvminfo Description Displays KVM module information. To run this subcommand, you must have the CMC Login User privilege.
Output ● LED is blinking ● LED is not-blinking Example ● racadm getled -m server-10 server-10 Blinking ● racadm getled -m chassis server-10 Not blinking ● racadm getled -m server-1 server-1 ON ● racadm getled -m server-9 server-9 Extension(1) getmacaddress Description Displays the MAC/WWN addresses and fabric ID decoder for all modules or for a specified module.
switch-, where n=1–6 ● -t — Displays the iSCSI MAC addresses for all servers or the specified server if used with -m option. ● -x — Displays the extra MACs (Ethernet or iSCSI) for servers with additional LOM MACs and must be used with -m option. ● -a — Displays the Ethernet and iSCSI MAC/WWN addresses for all iDRAC or LOMs or mezzanine cards. When FlexAddress is enabled for a particular slot, then the chassis-assigned MAC/WWN address is displayed.
CMC Present N/A F0:4D:A2:77:71: 72 N/A racadm getmacaddress -m switch-1 Switch-1 Present Not Installed 00:00:00:00:00: 00 Not Installed Display MAC for server-1.
Server-1 Present 00:1E:4F:2A:AF: 7B 00:1E:4F:2A:D3: 97 00:1E:4F:2A:D3: 99 Server-2 Present 00:22:19:D2:1E: 84 N/A N/A Server-3 Not Present N/A N/A N/A Server-4 Present 00:18:8B:FF:45: 2A 00:18:8B:FF:AA: 02 00:18:8B:FF:AA: 04 Switch-1 Present N/A 00:00:00:00:00: 00 N/A Displays the Ethernet and iSCSI MAC/WWN addresses for all iDRAC or LOMs or mezzanine cards.
iSCSI Present Not Installed Not Installed Server-2-C Fibre Channel 4 Present Not Installed Not Installed Server-3 N/A Not Present N/A N/A N/A Server-4-A Gigabit Ethernet Present 00:18:8B:FF :45:2A 00:18:8B:FF :AA:02 00:18:8B:FF :AA:04 iSCSI Present 00:18:8B:FF :AA:03 00:18:8B:FF :AA:05 Gigabit Ethernet Not Present Not Installed Not Installed iSCSI Present Not Installed Not Installed Server-4-C Fibre Channel 4 Present Not Installed Not Installed Switch-1 None Present
Server-7A IDRACController Present 84:8F:69:D8: B1:BD N/A Factory 10 GbE KR/3 Present 00:90:FA:51: 34:F5 Unknown Factory 10 GbE KR/3 Present 00:90:FA:51: 34:FD Unknown Factory Switch-1 10 GbE KR Present 00:1E:C9:F1: 04:94 N/A Factory Switch-5 10 GbE KR Present 00:00:00:00: 00:00 N/A Factory NOTE: 10 GbE KR/3— The value 3 indicates that the fabric is iSCSI/FCoE-FIP. Displays the chassis-assigned WWN/MAC address.
CMC N/A Present 34:17:EB:E6:E 0:24 N/A Factory server-1 -A 10 GbE KR Not Installed 10:98:36:AC:7 0:EB Not Installed Not Installed Server-2 Not Installed Not Present Not Installed Not Installed Not Installed Server-3 -A Reserved Present Switch-4 Not Installed Not Present Not Installed Not Installed Not Installed Switch-1 Not Installed Not Present Not Installed N/A N/A NOTE: If the I/O Modules in slots 1 and 2 are absent and the getmacaddress -a and getmacaddress —c all comman
Examples Display status of all the modules in the chassis racadm getmodinfo Display status of fan module 3 in the chassis racadm getmodinfo -m fan-3 ● racadm getmodinfo -m switch-1 Switch-1 Present ON OK 0000000 N/A ● racadm getmodinfo Chassis Present ON Not OK noble01 N/A Fan-1 Present ON OK N/A N/A Fan-2 Present ON OK N/A N/A Fan-3 Present ON OK N/A N/A Fa
Server-3 Present ON OK BCD1234 BCD1234 Server-4 Present ON OK BCD1234 BCD1234 Server-5 Present ON OK BCD1234 BCD1234 Server-6 Present ON OK BCD1234 BCD1234 Server-7 Present ON OK BCD1234 BCD1234 Server-8 Present ON OK BCD1234 BCD1234 Server-9 Present ON OK BCD1234 BCD1234 Server-10 Present ON OK ABC1234 ABC1234 Server-11 Present ON OK ABC1234 ABC1234 Server-12 Present ON OK BCD1234 BCD1234 Server-13 Present ON OK BCD1234 BCD1234 Server-14 Pr
IPv6 Enabled =1 DHCP6 Enabled =0 IP Address 1 =2000:de11:bcd1:fc14:1234:5678:2468:abcd Gateway =:: Link Local Address =fe80::f21f:afff:fed0:82d6/64 IP Address 2 =:: IP Address 3 =:: IP Address 4 =:: IP Address 5 =:: IP Address 6 =:: IP Address 7 =:: IP Address 8 =:: IP Address 9 =:: IP Address 10 =:: IP Address 11 =:: IP Address 12 =:: IP Address 13 =:: IP Address 14 =:: IP Address 15 =:: LOM Status: NIC Selection =dedicated Link Detected =Yes Speed =1Gb/s Duplex
getpbinfo Description Displays power budget status information. To run this subcommand, you must have the CMC Login User privilege.
EPP Percent - Available = 0.0 [Chassis Power Supply Status Table]
Synopsis Input racadm getpminfo N/A Example: Displays power management status information: racadm getpminfo [Real-Time Power Statistics] System Input Power = 1661 W (5667 BTU/h) Peak System Power = 1916 W (6537 BTU/h) Peak System Power Start Time = 09:19:27 11/26/2014 Peak System Power Timestamp = 09:29:20 11/26/2014 Minimum System Power = 35 W (119 BTU/h) Minimum System Power Start Time = 09:19:27 11/26/2014 Minimum System Power Timestamp = 09:54:00 11/26/2014 System Idle Power = 1661 W (
getraclog Description Synopsis The getraclog command displays CMC log entries. ● racadm getraclog [-i] ● racadm getraclog [-s ] [-c ] [--more] NOTE: If options are not provided, the entire log is displayed. Input ● -c — Specifies the number of records to display. NOTE: On Remote RACADM, the number of logs are restricted to 25 by default. ● -i — Displays the number of entries in the CMC log.
Timestamp Message Arg Message Arg Message sid=4818 = 2014-10-18 15:48:10 1 = 14503 2 = 48186 = Successfully closed Session process: pid=14503 getractime Description Displays the current CMC time. Synopsis ● racadm getractime [-d] ● racadm getractime [-d] [-z] ● racadm getractime [-n] Input ● -d — Displays the time in the format, YYYYMMDDhhmmss. ● -z — Displays timezone. ● -n — Displays NTP peer information.
● -c — Specifies the number of records to display. ● -m — Must be one of the following values: ○ server- : where n = 1–16 ○ server- : where n = 1–8; x = a, b, c, d (lower case) ● --more — Displays one screen at a time and prompts the user to continue (similar to the UNIX more command.) ● Display entire log. Example racadm getsel ● Display number of records in log. racadm getsel -i getsensorinfo Description Displays the status for system sensors.
PWR 3 PS-3 Online OK PWR 4 PS-4 Slot Empty N/A PWR 5 PS-5 Failed OK PWR 6 PS-6 Slot Empty N/A Cable 1 IO-Cable OK Cable 2 FPC-Cable OK racadm getsensorinfo -c Sensor Type: FanSpeed 1 Fan-1 OK 5515 rpm N/A 3508 N/A 9034 2 Fan-2 OK 5762 rpm N/A 3697 N/A 9034 3 Fan-3 OK 5786 rpm N/A 3697 N/A 9034 4 Fan-4 OK 5534 rpm N/A 3508 N/A 9034 5 Fan-5
2 FPC-Cable OK getslotname Description Displays the name of the slot in the chassis. Optionally, this command can be used to find if the slot name, host name, or iDRAC DNS name is displayed in the CMC User Interface or with the getslotname —i | —h command.
13 14 15 16 SLOT-13 SLOT-14 SLOT-15 SLOT-16 getssninfo Table 5. getssninfo Description Displays a list of users that are connected to CMC. The following information is displayed: ● Session ID ● Username ● IP address (if applicable) ● Session type (for example, serial or Telnet) ● Login date and time in MM/DD/YYYY HH:MM:SS format NOTE: Based on the Session ID (SSNID) or the user name (User), the CMC administrator can close the respective sessions or all the sessions using the closessn subcommand.
Example ● Display Service tag of Server in Slot 1 racadm getsvctag -m server-1 ● Display Service tag of all the components in the chassis racadm getsvctag getsysinfo Description Displays information related to CMC, managed system, and watchdog configuration. NOTE: The host name and OS Name fields in the getsysinfo output display accurate information only if the Dell OpenManage Server Administrator is installed on the managed system. Else, these fields may be blank or inaccurate.
Current IPv6 Address 1 Current IPv6 Gateway Current IPv6 DNS Server Current IPv6 DNS Server DNS Servers from DHCPv6 = = 1 2 :: :: = :: = :: = 0 Chassis Information: System Model = System AssetTag = Service Tag = Chassis Name = Chassis Location = Chassis Midplane Version= Power Status = PowerEdge M1000e 12345678901234567890123456781234456771234567890asvcdefrtghyhytg JGB6B2S CMC-JGB6B2S 3rdflor 1.
● Display number of records in log racadm gettracelog -i Total Records: 228 getversion Description Displays the current software version, model and generation information, and whether the target device can be updated. Synopsis racadm getversion -m server-1 server-1 1.40.40 (Build 08) PowerEdge M520 iDRAC Y server-2 3.50 (Build 2) PowerEdgeM610x iDRAC6 Y server-4 3.
< Server > < Component > < Version > < Install Date > server-1 BIOS 1.6.0 2013-01-09 iDRAC1.40.40 1.40.40 2013-01-31 USC 1.1.5.154 2013-04-16 Diagnostics 4225A2 2012-12-21 OS Drivers 7.2.0.7 2012-12-21 BIOS 1.5.2 Rollback BP12G+ 0:1 0.16 Reinstall iDRAC 70 Rollback System CPLD 1.0.5 1999-12-31 NIC-Broadcom Gigabit Ethernet BCM5720 BC:30:5B:97:06:C4 7.6.6 Rollback NIC-Broadcom Gigabit Ethernet BCM5720 BC:30:5B:97:06:C4 7.6.
NIC-Broadcom Gigabit Ethernet BCM5720 BC:30:5B:97:06:C6 7.6.12 NIC-PERC S110 Controller 3.0.0-0139 RAID-PERC H310 Mini 20.10.1-0084 RAID-PERC H310 Mini 2013-04-02 2012-10-11 Reinstall 20.10.1-0084 Reinstall RAID-PERC H310 Mini 20.10.1-0084 2012-02-09 BP12G+ 0:1 0.16 1999-12-31 racadm getversion -l -m server-1 -f bios < Server > < Component > < Version > < Install Date > server-1 BIOS 1.6.0 2013-01-09 ifconfig Description Displays the contents of the network interface table.
krbkeytabupload Description Uploads a Kerberos keytab file to CMC. To run this subcommand, you must have the Configure Chassis Administrator privilege. NOTE: This subcommand is only supported on the remote interface(s). Synopsis racadm krbkeytabupload [-f ] is the name of the file including the path. Input -f — Specifies the filename of the keytab uploaded. If the file is not specified, the keytab file in the current directory is selected.
tcp 0 0 127.0.0.1:8195 127.0.0.1:52887 ESTABLISHED tcp 0 0 127.0.0.1:52175 127.0.0.1:199 ESTABLISHED tcp 0 0 127.0.0.1:199 127.0.0.1:52175 ESTABLISHED tcp 0 0 192.168.0.32 192.168.0.31 ESTABLISHED tcp 0 0 127.0.0.1:52174 127.0.0.1:199 ESTABLISHED tcp 0 0 127.0.0.1:52887 127.0.0.1:8195 ESTABLISHED ping Description Verifies if the destination IP address is reachable from CMC with the current routing-table contents. A destination IP address is required.
racdump Description Provides a single command to get dump, status, and general CMC board information. This subcommand displays the comprehensive chassis status, configuration state information, and historic event logs. Used for post deployment configuration verification and during debugging sessions. To run this subcommand, you must have the Administrator privilege.
Chassis Information: System Model System AssetTag Service Tag Chassis Name Chassis Location Power Status = = = = = = PowerEdgeM1000eControlPanel 00000 Dell Rack System [UNDEFINED] ON =============================================================================== Session Information =============================================================================== Type SSH KVM User root root IP Address 192.168.0.2 169.254.31.
○ -f option is used to force the reset and is available only with an -m option. Output Example racadm racreset RAC reset operation initiated successfully. It may take up to a minute for the RAC to come online again. ● To reset CMC. racadm racreset ● To reset server 1 racadm racreset -m server-1 ● To reset servers 1 and 3 racadm racreset -m server-1 -m server-3 racresetcfg Description Deletes your current CMC configuration and resets CMC to the factory default settings.
NOTE: -c option is valid with only. NOTE: If chassis is the target of racresetcfg, CMC resets after the operation. Example ● Reset the KVM configuration on CMC. racadm racresetcfg -m kvm The configuration has initiated restoration to factory defaults. ● Reset blade 8 configuration from CMC. racadm racresetcfg -m server-8 The RAC configuration has initiated restoration to factory defaults. Wait up to a minute for this process to complete before accessing the RAC again.
● -e — Deploys a remote image. The first boot device is set to the shared image and the server is set to reboot. ● -m — Specifies the server to deploy the image to one of the following: ○ sever–, where n=1–16 ○ server– where n=1–8; x=a, b, c, d (lower case) ● -a — Applies options for slots for all present servers. NOTE: The following options only apply to connect and deploy actions ● -u — Username. User name to access the network share.
● Configure a CMC from an XML configuration file on a local share using remote racadm racadm -r 192.168.0.120 -u -p set -f myfile.xml -t xml ● Configure a CMC from an XML configuration file on a remote CIFS share racadm set -f myfile.xml -t xml -u myuser -p mypass -l // 192.168.0.0/myshare ● Configure a CMC from an XML configuration file on a remote NFS share racadm set -f myfile.xml -t xml -l 192.168.0.
Example ● Power down the operating system on the server by using the following command: racadm serveraction powerdown Powers down the managed system ● Reseat blade 2 on CMC by using the following command: racadm serveraction -m server-2 reseat -f Server power operation successful ● Turn off the server 16 from CMC by using the following command: racadm serveraction -m server-16 powerdown Server power operation successful ● Get Power Status of blade 16 on CMC by using the following command: racadm serveracti
● — Group Membership Management Password is required when adding members to the group. The password must have 3 to 16 alphanumeric characters and is case-sensitive. ● — Group Administration Password to set admin password when creating new group and overrides the factory-set password. grpadmin is the default grpadmin account. The password must have 3 to 16 alphanumeric characters and is case-sensitive. ● —f — The valid values are A or B. Select Fabric used for data I/O.
NOTE: The special characters “ (double quotation mark), ‘ (backward quotation mark), & (ampersand), > (greater than), < (less than), and \ (backward slash) are not supported for this subcommand. Synopsis racadm setchassisname NOTE: Chassis name is a maximum of 64 nonextended ASCII characters. Example racadm setchassisname dellchassis-1 The chassis name was set successfully. setflexaddr Description Enables or disables FlexAddress on a particular slot or fabric.
To blink or unblink the chassis, I/O modules or the CMC, you must have the Debug Administrator privilege. To enable the servers to blink or unblink, you must have the Server Administrator or the Debug Administrator privilege. Synopsis Input racadm setled -m -l ● -m — Specifies the module whose LED you want to configure.
Input ● racadm setniccfg [-m ] -k [ ] ● racadm setniccfg [-i ] -v [ ] ● -d — Enables DHCP for the NIC. It is enabled by default. ● -d6 — Enables AutoConfig for the NIC (default is disabled). ● -s — Enables static IP settings. The IPv4 address, netmask, and gateway must be specified. Otherwise, the existing static settings are used. , , and must be typed as dot-separated strings. racadm setniccfg -s 192.168.0 255.255.255.
● Configuration of redundant mode racadm setniccfg -r 1 setractime Description Sets the date and time on the CMC. To run this subcommand, you must have the Administrator privilege. Synopsis Input ● racadm setractime -d ● racadm setractime -l ● racadm setractime -z ?||* ● -d ○ ○ ○ ○ ○ ○ ○ ○ ○ — Sets the time in the string YYYYMMDDhhmmss.
● To set the local time to November 24, 2012 at 3:02:30 pm racadm setractime -l 20121124150230 The time was set successfully ● Set the timezone to 'US/Pacific': racadm setractime -z US/Pacific ● List all 'US' time zones: racadm setractime -z US* setslotname Description Sets the name of the slot in the chassis. Optionally, this command can be used to find if the slot name, host name, or iDRAC DNS name is displayed in the CMC User Interface or with the setslotname —i | —h command.
NOTE: The special characters “ (double quotation mark), ‘ (backward quotation mark), & (ampersand), > (greater than), < (less than), and \ (backward slash) are not supported for this subcommand. Synopsis Input Example racadm setsysinfo -c chassisname|chassislocation ● — Indicates a maximum of 64 nonextended ASCII chassis name or location. ● -c — Sets the chassis name or location.
● Upload an invalid key to iDRAC User 2 in the first key space using a string. $ racadm sshpkauth -i 2 -k 1 -t "This is invalid key Text" ERROR: Key text appears to be corrupt ● Upload a valid key to iDRAC User 2 in the first key space using a file. $ racadm sshpkauth -i 2 -k 1 -f pkkey.key Key file successfully uploaded. ● Get all keys for User 2 on iDRAC.
NOTE: This command is not supported in the firmware RACADM interface as it is not a file system. sslcertupload Description Uploads a custom SSL server or CA certificate for Directory Service from the client to CMC. To run this subcommand, you must have the Server Control privilege. NOTE: This subcommand is only supported on the remote interfaces. Synopsis Input Output racadm sslcertupload -f -t ● -t ○ ○ ○ ○ ● -f ● -k — Specifies the type of certificate to upload.
racadm sslcertview -t 1 Serial Number 01 Subject Information: Country Code (CC) US State (S) Texas Locality (L) Round Rock Organization (O) Dell Inc. Organizational Unit (OU) Remote Access Group Common Name (CN) CMC Default certificate Issuer Information: Country Code (CC) US State (S) Texas Locality (L) Round Rock Organization (O) Dell Inc.
racadm sslcertview -t 1 -A 00 US Texas Round Rock Dell Inc. Remote Access Group CMC default certificate US Texas Round Rock Dell Inc. Remote Access Group CMC default certificate Jun 7 23:54:19 2011 GMT Jun 4 23:54:19 2021 GMT sslcsrgen Description Generates and downloads a certificate signing request (CSR) file to the client’s local file system. The CSR can be used for creating a custom SSL certificate that can be used for SSL transactions on CMC.
Output If no options are specified, a CSR is generated and downloaded to the local file system as sslcsr by default. The -g option cannot be used with the -s option, and the -f option can only be used with the -g option. The sslcsrgen -s subcommand returns one of the following status codes: ● CSR was generated successfully. ● CSR does not exist. Example ● Display current status of CSR operation: racadm sslcsrgen -s or racadm sslcsrgen -g -f c:\csr\csrtest.
Input Output -i — Specifies the index of the email alert to test. Success: Test e-mail sent successfully Failure: Unable to send test e-mail Example ● Send a test email to the destination email address configured for index 1 racadm testemail -i 1 testfeature Description Synopsis Input Tests CMC feature x.
testtrap Description Tests the RAC’s SNMP trap alerting feature by sending a test trap from CMC to a specified destination trap listener on the network. To run this subcommand, you must have the Test Alert permission. NOTE: Before you run the testtrap subcommand, make sure that the specified index in the cfgAlerting group is configured properly. Synopsis racadm testtrap -i Input -i — Specifies the index of the trap configuration that must be used for the test.
3 CMC Property Database Group and Object Descriptions CMC property database contains the configuration information. Associated object is organizing data, and object group is organizing object. The IDs for the groups and objects that the property database supports are listed in this section. To configure CMC, use the group and object IDs with the RACADM subcommands. NOTE: You can configure a setting that does not have a hash symbol (#) as the prefix in its output name.
abcdefghijklmnopqrstuvwxwz ABCDEFGHIJKLMNOPQRSTUVWXYZ 0123456789~`!@#$%^&*()_+-={}[]|\:";'<>,.?/ The following table provides an overview of the object groups.
idRacInfo This group contains display parameters to provide information about the specifics of CMC being queried. One instance of the group is allowed. Use this object with the getconfig subcommand. To use this object, you must have the CMC Login User privilege. The following sections provide information about the objects in the idRACInfo group. idRacProductInfo (Read Only) Description A text string that identifies the product. Legal Values A string of up to 63 ASCII characters.
iDRAC Type (Read Only) Description Identifies the remote access controller type.
cfgNicVLanEnable (Read or Write) Description Enables or disables the VLAN capabilities. All chassis management traffic, including the CMC and all iDRACs, resides on this external VLAN when enabled. No iDRAC configuration change is required to use this external management network VLAN.
NOTE: Microsoft Active Directory only supports Fully Qualified Domain Names (FQDN) of 64 bytes or fewer. Default cfgDNSDomainNameFromDHCP (Read or Write) Description Specifies that CMC DNS domain name must be assigned from the network DHCP server. Legal Values ● 1 — True ● 0 — False Default 0 This property is used only if cfgNicUseDhcp is set to 1(true), or if both cfgIPv6Enable and cfgIPv6AutoConfig are set to 1(true).
cfgDNSRacName (Read or Write) Description Displays the CMC name, which is Service Tag by default. This parameter is only valid if cfgDNSRegisterRac is set to 1 (TRUE). Legal Values A string of up to 63 ASCII characters. At least one character must be alphabetic. NOTE: Some DNS servers only register names of 31 characters or fewer. Default cmc- cfgDNSRegisterRac (Read or Write) Description Registers the iDRAC or CMC name on the DNS server.
Example: racadm getconfig -g cfgLanNetworking cfgNicEnable=1 cfgNicIPv4Enable=1 cfgNicIpAddress=192.168.22.101 cfgNicNetmask=255.255.255.0 cfgNicGateway=192.168.22.101 cfgNicUseDhcp=1 # cfgNicMacAddress=00:00:00:00:00:01 cfgNicVLanEnable=0 cfgNicVLanID=1 cfgNicVLanPriority=0 cfgDNSServersFromDHCP=1 cfgDNSServer1=192.168.0.5 cfgDNSServer2=192.168.0.6 cfgDNSRacName=cmc-frankly cfgDNSDomainName=fwad.
cfgNicEnable (Read or Write) Description Enables or disables CMC network interface controller (NIC). If the NIC is disabled, the remote network interfaces to CMC are no longer accessible and CMC is only available through the local or serial RACADM interface. Legal Values ● 1 (TRUE) ● 0 (FALSE) Default 1 cfgNicIpAddress (Read or Write) Description Specifies the static IPv4 address. NOTE: This parameter is only configurable if the cfgNicUseDhcp parameter is set to 0(FALSE).
Legal Values ● 1 (TRUE) ● 0 (FALSE) Default 0 cfgNicMacAddress (Read Only) Description The NIC MAC address in the format: dd:dd:dd:dd:dd:dd, where d is a hexadecimal digit in range 0 – 9, A — F Legal Values String representing NIC MAC address. Default The current MAC address of NIC. For example, 00:12:67:52:51:A3. cfgRemoteHosts This group provides properties that allow configuration of the SMTP server for email alerts.
cfgRhostsSmtpServerIpAddr (Read or Write) Description The IPv4 or IPv6 address of the network SMTP server. The SMTP server transmits email alerts from CMC if the alerts are configured and enabled. Legal Values A string representing a valid SMTP server IPv4 or IPv6 address. For example: 192.168.0.2. Default localhost.localdomain cfgRhostsNtpEnable (Read or Write) Description Enables or disables the use of the Network Time Protocol (NTP) for date and time synchronization.
Default 16 cfgRhostsSyslogEnable (Read or Write) Description To allow the RAC and SEL logs to be written to up to three remote syslog servers Enables or disables remote syslog. Legal Values ● 1 (TRUE) ● 0 (FALSE) Default 0 cfgRhostsSyslogPort (Read or Write) Description Remote syslog port number to use for writing the RAC and SEL logs to a remote syslog server. This setting takes effect only if the cfgRhostsSyslogEnable parameter is set to 1(enabled).
cfgRhostsSyslogPowerLoggingEnabled (Read or Write) Description To remote syslog servers, Enables or disables power consumption logging. NOTE: Remote syslog must be enabled and more than one remote syslog servers must be configured to log the power consumption. Legal Values ● 1 — Enabled ● 0 — Disabled Default 0 cfgRhostsSyslogPowerLoggingInterval (Read or Write) Description Specifies the power consumption collection/logging interval.
cfgUserAdminIndex (Read Only) Description The unique index of a user. The index number is used to specify a unique group name. Only valid for indexed groups. Legal Values The parameter specifies decimal integer 1–16. Default cfgUserAdminPrivilege (Read or Write) Description This property specifies the role-based authority privileges allowed for the user. The value is represented as a bit mask that allows for any combination of privilege values.
CMC Login User 0x0000001 Chassis Configuration Administrator 0x0000002 User Configuration Administrator 0x0000004 Clear Logs Administrator 0x0000008 Chassis Control Administrator 0x0000010 Super User 0x0000020 Server Administrator 0x0000040 Test Alert User 0x0000080 Debug Command Administrator 0x0000100 Fabric A Administrator 0x0000200 Fabric B Administrator 0x0000400 Fabric C Administrator 0x0000800 Examples The following table provides sample privilege bit masks for users with one
access Virtual Media, and Virtual Console. cfgUserAdminUserName (Read or Write) Description The name of the user for this index. Writing a string of double quotation mark (" ") disables the user. The string cannot contain / (forward slash), \ (backward slash), . (period), @ (at symbol), quotation marks, ; (semicolon), or ‘ (backward quotation mark). NOTE: This property value must be unique among user names. Legal Values A string of up to 16 ASCII characters.
Legal Values 1–4 Default cfgEmailAlertEnable (Read or Write) Description Enables or disables the alert instance. Legal Values ● 1 (TRUE) ● 0 (FALSE) Default 0 cfgEmailAlertAddress (Read or Write) Description Specifies the destination email address for email alerts, for example, user1@company.com. Legal Values Email address format, with a maximum length of 64 ASCII characters.
Legal Values 10–1920 Default 30 minutes Example racadm getconfig -g cfgSessionManagement cfgSsnMgtWebserverTimeout=0 cfgSsnMgtTelnetIdleTimeout=0 cfgSsnMgtSshIdleTimeout=1800 cfgSsnMgtRacadmTimeout=0 cfgSsnMgtWebserverTimeout (Read or Write) Description Defines the web server time-out. This property sets the amount of time (in seconds) that a connection is allowed to remain idle (there is no user input). The session is canceled if the time limit exceeds this property.
cfgSerial This group contains configuration parameters for the serial configuration. One instance of the group is allowed. Use this object with the config or getconfig subcommands. To use this object property, you must have the Chassis Configuration Administrator privilege. The following sections provide information about the objects in the cfgSerial group. cfgSerialBaudRate (Read or Write) Description Sets the baud rate on the serial port.
Legal Values ● 0 = No timeout ● 60–1920 Default 1800 cfgSerialConsoleNoAuth (Read or Write) Description Enables or disables the serial console login authentication. Legal Values ● 0 — (enables serial login authentication) ● 1 — (disables serial login authentication) Default 0 cfgSerialConsoleCommand (Read or Write) Description Specifies a serial command that is executed after a user logs in to the serial console interface. Legal Values A string representing a valid serial command.
Default 1 Example racadm getconfig -g cfgSerial cfgSerialBaudRate=115200 cfgSerialConsoleEnable=1 cfgSerialConsoleQuitKey=^\ cfgSerialConsoleIdleTimeout=1800 cfgSerialConsoleNoAuth=0 cfgSerialConsoleCommand= cfgSerialConsoleColumns=0 cfgSerialHistorySize=8192 cfgSerialTelnetEnable=0 cfgSerialSshEnable=1 cfgSerialTelnetEnable (Read or Write) Description Enables or disables the Telnet console interface.
cfgOobSnmpAgentEnable (Read or Write) Description Enables or disables the SNMP agent in CMC. Legal Values ● 1 (TRUE) ● 0 (FALSE) Default 0 cfgOobSnmpProtocol Description Specifies the SNMP protocol used for SNMP traps. Legal Values ● 0 — All ● 1 — SNMPv3 Default 0 cfgOobSnmpTrapFormat Description Specifies the format for SNMP traps.
● 0 (FALSE) Default None cfgTrapsAlertDestIPAddr (Read or Write) Description Sets the IP address that receives the alert. Legal Values A string representing a valid IP address. For example, 192.168.0.20. Default None cfgTrapsCommunityName (Read or Write) Description Sets the community string (identical to the community name) used for authentication. The community string acts as a password shared between different hosts over the network.
cfgRacTuning This group is used to configure various configuration properties, such as valid ports and security port restrictions. Use this object with the config or getconfig subcommands. To use this object property, you must have the Chassis Configuration Administrator privilege. NOTE: You can configure a setting that does not have the hash sign (#) prefixed in the output. To modify a configurable object, use the —o option.
NOTE: The following port numbers are reserved and cannot be used: 21, 68, 69, 111, 123, 161, 546, 801, 4096, 5988, 5989, 6900, 9000, and 60106. Default 80 cfgRacTuneHttpsPort (Read or Write) Description To use HTTPS network communication, specify the port number. Legal Values 10–65535 NOTE: The following port numbers are reserved and cannot be used: 21, 68, 69, 111, 123, 161, 546, 801, 4096, 5988, 5989, 6900, 9000, and 60106.
cfgRacTuneIpBlkEnable (Read or Write) Description Enables or disables the IPv4 address blocking feature. Legal Values ● 1 (TRUE) ● 0 (FALSE) Default 0 cfgRacTuneIpBlkFailCount (Read or Write) Description The maximum number of logins that is not successful, to occur within the window (cfgRacTuneIpBlkFailWindow) before log in attempt from the IP address is rejected.
cfgRacTuneUserBlkEnable (Read or Write) Description Blocks the login for maximum of 5 minutes after 5 unsuccessful login attempts. The login using any interface such as WSMAN or GUI is blocked after 5 unsuccessful attempts NOTE: This is applicable only to configure the user privilege. Legal Values ● 1 — Enabled ● 0 — Disabled Default 0 — Disabled cfgRacTuneSshPort (Read or Write) Description Specifies the port number used for the SSH interface.
cfgRacTuneTelnetPort=23 cfgRacTuneSshPort=22 cfgRacTuneIpRangeEnable=0 cfgRacTuneIpRangeAddr=192.168.1.1 cfgRacTuneIpRangeMask=255.255.255.0 # cfgRacTuneTimezoneOffset=-18000 # cfgRacTuneDaylightOffset=3600 cfgRacTuneTimezoneOffset (Read Only) Description This object property is read only. Specifies the difference in number of seconds, from the UTC/GMT. This value is negative if the current time zone is west of Greenwich.
cfgRacTuneTLSProtocolVersionEnable Description Sets the minimum TLS protocol version. Legal Values ● 0 - TLSv1.0, TLSv1.1, and TLSv1.2 are enabled. ● 1 - TLSv1.1 and TLSv1.2 are enabled. ● 2 - only TLSv1.2 is enabled. Default 1 cfgServerInfo This group allows you to display and configure a server in the chassis. Use this object with the config or getconfig subcommands. To use this object property, you must have the Chassis Configuration Administrator privilege.
Legal Values Maximum of 15 non-extended (ASCII characters (ASCII codes 32 through 126). For more information, see Guidelines to Quote Strings Containing Special Characters. Default SLOT — cfgServerFW (Read Only) Description Displays the server's iDRAC firmware revision. Legal Values None Default None cfgServerBIOS (Read Only) Description Displays the server's BIOS revision.
Default 1 NOTE: You can set the cfgServerPriority for a slot using quarter-width blade servers. For example: config -g cfgserverinfo -o cfgserverpriority -i 6a 9 cfgServerNicEnable (Read or Write) Description Enables or disables LAN channel. Legal Values ● 1 — Enable ● 0 — Disable Default None cfgServerIPMIOverLanEnable (Read or Write) Description Enables or disables IPMI LAN channel.
cfgServerRootPassword (Write Only) Description Displays the password for IMC as a series of asterisks (*). It cannot be seen or displayed after this property is written. Legal Values None Default None cfgServerFirstBootDevice (Read or Write) Description Sets or displays the first boot device. NOTE: First attach, to configure vFlash as First Boot Device.
# cfgServerInfoIndex=1a # cfgServerSlotNumber=1a # cfgServerServiceTag=ABC1234 cfgServerName=SLOT-01a # cfgServerFW=1.57.57 (Build 04) # cfgServerBIOS=2.3.
cfgADRootDomain (Read or Write) Description Specifies the root domain of the domain forest. Legal Values Any printable text string of up to 254 characters, with no white space. Default cfgADEnable (Read or Write) Description Enables or disables Active Directory user authentication on CMC. If this property is disabled then either local CMC or LDAP authentication may be used for user login.
Legal Values 15–300 seconds Default 120 cfgADType (Read or Write) Description To use the Active Directory, determine the schema type. Legal Values ● 1— (Enables Active Directory with the extended schema) ● 2— (Enables Active Directory with the standard schema) Default 1 cfgADSpecifyServerEnable (Read or Write) Description Allows you to enable or disable and specify an LDAP server or a global catalog server. To specify the IP address, use either cfgADDomainController or cfgADGlobalCatalog.
Legal Values ● 1 (TRUE) ● 0 (FALSE) Default 1 cfgLDAP This group allows you to configure settings related to the Lightweight Directory Access Protocol (LDAP). Use this object with the config or getconfig subcommands. To use this object property, you must have the Chassis Configuration Administrator privilege. NOTE: You can configure a setting that does not have the hash sign (#) prefixed in the output. To modify a configurable object, use the —o option.
cfgLDAPBaseDN (Read or Write) Description The domain name of the branch of the directory where all searches must start. Legal Values String. Maximum length = 254 Default Null cfgLDAPUserAttribute (Read or Write) Description To search for, specify the user attribute. It is recommended to be unique within the chosen baseDN, otherwise a search filter must be configured to make sure the uniqueness of the login user. If the userDN cannot be uniquely identified, login is unsuccessful with error.
cfgLDAPBindPassword (Write Only) Description A bind password is used with the bindDN. The bind password is a sensitive data, and must be protected. It is optional to support anonymous bind. Legal Values String maximum length = 254 Default Null cfgLDAPSearchFilter (Read or Write) Description To validate LDAP search filter, use the user attribute that cannot uniquely identify the login user within the chosen baseDN. The search filter only applies to userDN search and not the group membership search.
Default 0 cfgLDAPSRVLookupDomainName (Read Only) Description To use in the SRV lookup, configure the domain name. Legal Values String of maximum length of 254 alphanumeric characters and hyphens. The string must begin with a letter. Default [null] cfgLDAPSRVLookupServiceName (Read or Write) Description To use in the SRV lookup, configure the service name. Legal Values String of maximum length of 254 characters.
Legal Values String maximum length = 1024 Default None Example racadm getconfig -g cfgLDAPRoleGroup -o cfgLDAPRoleGroupDN -i 1 cfgLDAPRoleGroupPrivilege (Read or Write) Description A bit–mask defining the privileges associated with this particular group.
cfgSSADRoleGroupDomain (Read or Write) Description Active Directory Domain in which the Role Group resides. Legal Values Any printable text string of up to 254 characters, with no white space. Default cfgSSADRoleGroupPrivilege (Read or Write) Description Use the bit mask numbers listed in the table below to set role-based authority privileges for a Role Group.
cfgLocationRackslot (Read or Write) Description Indicates slot where server is located. Legal Values Values 1–255 (1 Byte) Default 0 cfgLocationDeviceSize (Read Only) Description Indicates server chassis size. Legal Values Values 1–255 Default 0 cfgChassisPower This group contains parameters to display or configure power for the chassis. Use this object with the config or getconfig subcommands. To use this object property, you must have the Chassis Configuration Administrator privilege.
cfgChassisInPower (Read Only) Description Indicates the cumulative input power consumption data (in watts and BTU/hr) captured from all healthy and functional PSUs in the chassis. Legal Values None Default None cfgChassisPeakPower (Read Only) Description Since the user has cleared last value, the system power consumption (in watts) is maximum.
● 5 — (critical) ● 6 — (nonrecoverable) Default None cfgChassisRedundantState (Read or Write) Description Enables or disables power redundancy for the chassis. Legal Values ● 0 — No Redundancy ● 1 — Grid Redundancy ● 2 — PSU Redundancy Default 0 cfgChassisDefaultPowerCapLowerBoundBTU (Read Only) Description Displays the default power cap lower bound value using British Thermal Unit (BTU).
cfgChassisPowerCap (Read or Write) Description Indicates the maximum power consumption limit (in watts) for the entire chassis. The command generates an error if server throttling is necessary to achieve the power goal based on the value for this setting. Legal Values 2715–16685 watts Default 16685 watts cfgChassisPowerCapF (Read or Write) Description Indicates the maximum power consumption limit (in watts) for the entire chassis.
Default 100 cfgChassisPowerCapFPercent (Read or Write) Description Indicates the power consumption limit as a percentage. The percentage is computed mathematically as the minimum power + (percent * (maximum power — minimum power)). Use cfgChassisPowerCapFPercent when power consumption is changes regardless of whether server throttling is required. Legal Values 16–100 NOTE: If the specified percent is lower than the minimum value, the CMC sets the value to the minimum value.
cfgChassisMaxPowerConservationMode (Read or Write) Description Enables or disables maximum power conservation mode. When enabled, all servers are immediately reduced to their minimum power levels, and all subsequent server power allocation requests are denied. In this mode, performance of powered on servers may be degraded and more servers cannot be powered on, regardless of server priority.
cfgChassisInPowerServerAllocation (Read Only) Description Indicates (in watts) the cumulative power allocated to servers. There is no default as this parameter is specific to the particular customer configuration. Legal Values None Default None cfgChassisInfrastructureInPowerAllocation (Read Only) Description Indicates the estimated cumulative DC output power consumption (in watts), determined from a field replaceable unit (FRU) on the hardware modules in the chassis.
Default None cfgChassisPowerButtonEnable (Read or Write) Description Indicates if the chassis power button is enabled or disabled. Legal Values ● 0 — Disabled ● 1 — Enabled Default None cfgSystemEnergyConsumptionClear (Write Only) Description Resets energy statistics when set to 1.
cfgChassisACPowerRecoveryDisable Description If AC power recovery is disabled, the chassis is powered off after power outage is restored. Legal Values ● 0 — Enable ● 1 — Disable Default 0 cfgThermal This group displays and configures the thermal settings. Use this object with the config or getconfig subcommands. To set the configurations, you must have the Chassis Configuration Administrator privileges. cfgThermalMFSPercent (Read or Write) Description Configures the minimum fan speed in percent.
cfgKVMFrontPanelEnable (Read or Write) Description Enables or disables front panel access on the iKVM. Legal Values ● 1 (enable) ● 0 (disable) Default None Example racadm getconfig -g cfgKVMInfo cfgKVMAccessToCMCEnable=1 cfgKVMFrontPanelEnable=1 cfgLcdInfo This group is used to display information for and configure the LCD. To use this object property, you must have the Chassis Configuration Administrator privilege. The following section provides information about the object in cfgLcdInfo.
cfgAlertingFilterMask (Read or Write) Description Sets the event filter. Legal Values Hex values 0x0 — 0x1fffffff Default 0x17ff8db To use this object property, you must have Chassis Configuration Administrator privilege. cfgAlertingSourceEmailName (Read Only) Description Specifies the email address used to send email notifications when an event occurs.
Default “ :: “ cfgIPv6Gateway (Read or Write) Description CMC gateway IPv6 address. NOTE: This property is used only if cfgIPv6AutoConfig is set to 0 (false). Legal Values Specifies string representing a valid IPv6 entry. Default “ :: “ cfgIPv6PrefixLength (Read or Write) Description Specifies the prefix length for IPv6 address.
cfgIPv6DNSServer1 (Read or Write) Description Specifies the IPv6 DNS server address. NOTE: This property is used only if cfgIPv6DNSServersFromDHCP6 is set to 0 (false). Legal Values A string representing a valid IPv6 entry. For example, 2001:DB8:1234:5678:9ABC:DE11:C00C:BEEF Default “ :: “ cfgIPv6DNSServer2 (Read or Write) Description Specifies the IPv6 DNS server address. NOTE: This property is only valid if cfgIPv6DNSServersFromDHCP6 is set to 0 (false).
Use this object with the getconfig subcommand. To use this object property, you must have the CMC Login User privilege. Synopsis racadm getconfig -g cfgCurrentLanNetworking cfgNicCurrentIpAddress (Read Only) Description Displays the static IP address to the CMC.
cfgNicCurrentVlanID (Read Only) Description Indicates the Current Virtual Lan ID Legal Values Integer Default None cfgNicCurrentVlanPriority (Read Only) Description Indicates the Current Virtual Lan Priority. Legal Values Integer Default None cfgDNSCurrentServer1 (Read Only) Description Displays the IP address for DNS server 1. Legal Values A Valid IPv4 DNS IP Default 0.0.0.0 cfgDNSCurrentServer2 (Read Only) Description Displays the IP address for DNS server 2.
Example racadm getconfig -g cfgCurrentLanNetworking # cfgNicCurrentIPv4Enabled=1 # cfgNicCurrentIpAddress=143.166.152.116 # cfgNicCurrentNetmask=255.255.255.0 # cfgNicCurrentGateway=143.166.152.1 # cfgNicCurrentDhcpWasUsed=0 # cfgNicCurrentVlanEnable=0 # cfgNicCurrentVlanID=1 # cfgNicCurrentVlanPriority=0 # cfgDNSCurrentServer1=192.168.0.5 # cfgDNSCurrentServer2=192.168.0.6 # cfgDNSCurrentDomainName=MYDOMAIN cfgCurrentIPv6LanNetworking (Read Only) This group displays the current CMC IPv6 properties.
cfgCurrentIPv6Address (Read Only) Description Displays the current IPv6 addresses. This property displays up to 15 global IPv6 addresses, including stateful and stateless addresses. Legal Values 1 Default 0 cfgCurrentIPv6Gateway (Read Only) Description Displays the current IPv6 gateway. Legal Values None Default None cfgCurrentIPv6DNSServersFromDHCP6 (Read Only) Description Indicates whether the DNS server addresses are assigned from the DHCPv6 server.
# cfgCurrentIPv6DNSServer1=2009:123::1 # cfgCurrentIPv6DNSServer2=:: cfgNetTuning This group enables users to configure the advanced network interface parameters. When configured, the updated settings may take up to a minute to become active. CAUTION: Use extra precaution when modifying properties in this group. Inappropriate modification of the properties in this group can result in your RAC NIC become inoperable. The following sections provide information about the objects in the cfgNetTuning group.
cfgNetTuningNicMtu (Read or Write) Description Indicated the maximum size of units in bytes transmitted by NIC. Legal Values 576–1500 Default 1500 NOTE: IPv6 requires a minimum MTU of 1280. If IPv6 is enabled, and cfgNetTuningMtu is set to a lower value, the CMC uses an MTU of 1280. cfgRacSecurity This group is used to configure settings related to CMC SSL certificate signing request (CSR) feature. The properties in this group must be configured before generating a CSR.
Legal Values A string of up to 128 characters. Default cfgRacSecCsrStateName (Read or Write) Description Specifies the CSR State Name (S). Legal Values A string of up to 128 characters. Default cfgRacSecCsrCountryCode (Read/Write) Description Specifies the CSR Country Code (CC). Legal Values A string of 2 alphabet country code. Default US cfgRacSecCsrEmailAddr (Read or Write) Description Specifies the CSR email address. Legal Values A string of up to 64 characters.
cfgQuickDeploy This group is used to configure IDRAC deployment settings. You must have blade administrator privileges for configuring the settings. cfgActionOnServerInsertion Table 8. cfgActionOnServerInsertion — Details Description Configures settings when a new server is inserted into the slot. Legal Values ● ● ● ● Default 0 0 1 2 3 — — — — No Action QuickDeploy Only Server Profile Only Quick Deploy and Server Profile cfgSetiDRACRootPasswordOnServerInsertion Table 9.
cfgEnableiDRACIPv4 Table 12. cfgEnableiDRACIPv4 — Details Description Enables IPv4 for each iDRAC in the chassis. Any iDRAC that is not IPv6 is always IPv4 enabled. Legal Values ● 0 — Disable ● 1 — Enable Default 1 cfgEnableiDRACIPMIOverLAN Table 13. cfgEnableiDRACIPMIOverLAN Description Enables IPMI over LAN channel for iDRAC when servers are inserted into the chassis. Legal Values ● 0 — Disable ● 1 — Enable Default 0 cfgEnableiDRACIPv4DHCP Table 14.
cfgiDRACIPv4Netmask Table 17. cfgiDRACIPv4Netmask — Details Description IPv4–specific subnet mask that is common to all iDRACs present in the chassis. Legal Values IP format Default 255.255.255.0 cfgEnableiDRACIPv6 Table 18. cfgEnableiDRACIPv6 — Details Enables IPv6 for each IPv6-capable iDRAC present in the chassis. Description Legal Values ● 0 — Disable ● 1 — Enable Default 0 cfgEnableiDRACIPv6AutoConfig Table 19.
Table 21. cfgiDRACIPv6Gateway — Details (continued) Default :: cfgReservedIPAddressNumbers Table 22. cfgReservedIPAddressNumbers — Details Description The number of static IPv4 addresses reserved for iDRACs in the chassis. Legal Values 32 Default 32 cfgUseCMCDNSSettings Table 23. cfgUseCMCDNSSettings — Details Description Propagates the CMC DNS Server settings (IPv4 and IPv6) to iDRAC when a blade server is inserted in the chassis.
