Table 20. User Types (continued)
Privilege Description
• Power cycle
• Graceful shutdown
• Server Reboot
Test Alert User User can send test alert messages.
Debug Command
Administrator
User can execute system diagnostic commands.
Fabric A Administrator User can set and configure the Fabric A IOM.
Fabric B Administrator User can set and configure the Fabric B, which corresponds to the first mezzanine card in the servers and is
connected to the fabric B circuitry in the shared PCIe subsystem in the main board.
Fabric C Administrator User can set and configure the Fabric C, which corresponds to the second mezzanine card in the servers
and is connected to the fabric C circuitry in the shared PCIe subsystem in the main board.
The CMC user groups provide a series of user groups that have preassigned user privileges.
NOTE: If you select Administrator, Power User, or Guest User, and then add or remove a privilege from the pre-defined
set, the CMC Group automatically changes to Custom.
Table 21. CMC Group Privileges
User Group Privileges Granted
Administrator
• CMC Login User
• Chassis Configuration Administrator
• User Configuration Administrator
• Clear Logs Administrator
• Server Administrator
• Test Alert User
• Debug Command Administrator
• Fabric A Administrator
Power User
• Login
• Clear Logs Administrator
• Chassis Control Administrator (Power commands)
• Server Administrator
• Test Alert User
• Fabric A Administrator
Guest User Login
Custom Select any combination of the following permissions:
• CMC Login User
• Chassis Configuration Administrator
• User Configuration Administrator
• Clear Logs Administrator
• Chassis Control Administrator (Power commands)
• Server Administrator
• Test Alert User
• Debug Command Administrator
• Fabric A Administrator
None No assigned permissions
Configuring User Accounts and Privileges 117
