If On-Change Propagation is selected, the member chassis take on the properties of the leader. If Manual Propagation is selected,
click Propagate whenever you want to propagate the chosen settings to member chassis. For more information on propagation of
leader chassis properties to member chassis, see the Online Help.
Server Inventory for MCM group
A group is a lead chassis that has 0 to 8 chassis group members. The Chassis Group Health page displays all the member chassis and
allows you to save the server inventory report to a le, using standard browser download capability. The report contains data for:
• All servers currently in all the group chassis (including the leader).
• Empty slots and extension slots (including full height and double width server modules).
Saving Server Inventory Report
To save the server inventory report using the CMC web interface:
1 In the left pane, select the Group.
2 On the Chassis Group Health page, click Save Inventory Report. The File Download dialog box is displayed asking you to open or
save the le.
3 Click Save and specify the path and le name for the server module inventory report.
NOTE
: The chassis group leader and chassis group member chassis, and the server module in the associated chassis, must
be turned on to get the most accurate server module inventory report.
Exported Data
The server inventory report contains data that was most recently returned by each Chassis Group member during the Chassis Group
leader’s normal polling (after every 30 seconds).
To get the most accurate server inventory report:
• The Chassis Group leader chassis and all Chassis Group member chassis must be in Chassis Power State On.
• All servers in the associated chassis must be turned on.
The inventory data for the associated chassis and servers may be missing in inventory report, if a subset of the Chassis Group member
chassis are:
• In Chassis Power State O state
• Turned o
NOTE
: If a server is inserted while the chassis is turned o, the model number is not displayed anywhere in the web interface
until the chassis is turned on again.
The following table lists the
specic data elds and specic requirements for elds to be reported for each server:
Table 17. Server Module Inventory Field Descriptions
Data Field Example
Chassis Name Data Center Chassis Leader
Chassis IP Address 192.168.0.1
Slot Location 1
92 Conguring CMC
