Updating Firmware
You can update rmware for:
• CMC
• Chassis infrastructure
• VRTX Expander or Storage Backplane Expander Firmware of Inegrated or external enclosures
• Physical Disks (HDD) per enclosure
NOTE: You can update the HDD rmware only if
required.
You can update rmware for the following I/O and server components:
• I/O Module
• BIOS
• iDRAC
• Lifecycle Controller
• 32–bit diagnostics
• Operating System Drivers Pack
• Network Interface Controllers
• RAID controllers on the server module
NOTE
: Firmware update may take several minutes to complete.
Topics:
• Downloading CMC Firmware
• Viewing Currently Installed Firmware Versions
• Updating the CMC Firmware
• Updating Chassis Infrastructure Firmware
• Updating Server iDRAC Firmware
• Updating Server Component Firmware
• Viewing Firmware Inventory
• Saving Chassis Inventory Report Using CMC Web Interface
• Conguring Network Share Using CMC Web Interface
• Lifecycle Controller Job Operations
• Rolling Back Server Component Firmware
• Upgrading Server Component Firmware
• Deleting Scheduled Server Component Firmware Jobs
• Updating Storage Component Using CMC Web Interface
• Recovering iDRAC Firmware Using CMC
Downloading CMC Firmware
Before beginning the rmware update, download the latest rmware version from support.dell.com, and save it to your local system.
4
Updating Firmware 51
