Situation Command Output
Guest user attempts to set FlexAddress
on slots/fabrics.
$racadm setflexaddr [-f
<fabricName> <slotState>]
$racadm setflexaddr [-i <slot#>
<slotstate>]
ERROR: Insufficient user
privileges to perform operation
Deactivating FlexAddress feature with
chassis powered ON.
$racadm feature -d -c
flexaddress
ERROR: Unable to deactivate the
feature because the chassis is
powered ON
Guest user tries to deactivate the feature
on the chassis.
$racadm feature -d -c
flexaddress
ERROR: Insufficient user
privileges to perform operation
Changing the slot/fabric FlexAddress
settings while the server modules are
powered ON.
$racadm setflexaddr -i 1 1
ERROR: Unable to perform the
set operation because it
affects a powered ON server
Changing the Flexaddress settings of slot
or fabric, when the CMC Enterprise
License is not installed.
$racadm setflexaddr -i<slotnum>
<status>
$racadm setflexaddr -
f<FabricName> <status>
ERROR: SWC0242 : A required
license is missing or expired.
Obtain an appropriate license
and try again, or contact your
service provider for additional
details.
NOTE: To resolve this issue, you
must have a FlexAddress Enablement
license.
FlexAddress DELL SOFTWARE LICENSE
AGREEMENT
This is a legal agreement between you, the user, and Dell Products L.P. or Dell Global B.V. ("Dell"). This agreement covers all software that
is distributed with the Dell product, for which there is no separate license agreement between you and the manufacturer or owner of the
software (collectively the "Software"). This agreement is not for the sale of Software or any other intellectual property. All title and
intellectual property rights in and to Software is owned by the manufacturer or owner of the Software. All rights not expressly granted
under this agreement are reserved by the manufacturer or owner of the Software. By opening or breaking the seal on the Software
packet(s), installing or downloading the Software, or using the Software that has been preloaded or is embedded in your product, you
agree to be bound by the terms of this agreement. If you do not agree to these terms, promptly return all Software items (disks, written
materials, and packaging) and delete any preloaded or embedded Software.
You may use one copy of the Software on only one computer at a time. If you have multiple licenses for the Software, you may use as many
copies at any time as you have licenses. "Use" means loading the Software in temporary memory or permanent storage on the computer.
Installation on a network server solely for distribution to other computers is not "use" if (but only if) you have a separate license for each
computer to which the Software is distributed. You must ensure that the number of persons using the Software installed on a network
server does not exceed the number of licenses that you have. If the number of users of Software installed on a network server exceeds the
number of licenses, you must purchase additional licenses until the number of licenses equals the number of users before allowing additional
users to use the Software. If you are a commercial customer of Dell or a Dell aliate, you hereby grant Dell, or an agent selected by Dell, the
right to perform an audit of your use of the Software during normal business hours, you agree to cooperate with Dell in such audit, and you
agree to provide Dell with all records reasonably related to your use of the Software. The audit is limited to verication of your compliance
with the terms of this agreement.
The Software is protected by United States copyright laws and international treaties. You may make one copy of the Software solely for
backup or archival purposes or transfer it to a single hard disk provided you keep the original solely for backup or archival purposes. You
may not rent or lease the Software 240 Using FlexAddress and FlexAdress Plus Cards or copy the written materials accompanying the
Software, but you may transfer the Software and all accompanying materials on a permanent basis as part of a sale or transfer of the Dell
170
Using FlexAddress and FlexAdress Plus
