– Specify a Domain — enter the domain name to use for the DNS lookup
• To enable CMC to use the specied Active Directory Domain Controller server addresses, select Specify Domain Controller
Addresses . These are the addresses of the domain controllers where the CMC device object and the associated objects are
located.
4 Click Apply to save the settings.
NOTE: You must apply the settings before continuing. If you do not apply the settings, the settings are lost when you
navigate to the next page.
5
In the Extended Schema Settings section, type the CMC device name and the domain name.
6 If you have enabled certicate validation, you must upload the domain forest root certicate authority-signed certicate to CMC. In
the Manage Certicates section, type the le path of the certicate or browse to the certicate le. Click Upload to upload the le to
CMC.
NOTE: The File Path value displays the relative le path of the certicate you are uploading. You must type the absolute
le path, which includes the full path and the complete le name and le extension.
The SSL certicates for the domain controllers must be signed by the root certicate authority-signed certicate. The root certicate
authority-signed certicate must be available on the management station accessing CMC.
CAUTION: SSL certicate validation is required by default. Disabling this certicate is not
recommended.
7 If you have enabled Single Sign-On (SSO), in the Kerberos Keytab section, click Browse, specify the keytab le and click Upload.
When the upload is complete, a message is displayed indicating a successful or failed upload.
8 Click Apply.
The CMC web server automatically restarts after you click Apply.
9 Log in to the CMC Web interface.
10 Select Chassis in the system tree, click the Network tab, and then click the Network subtab. The Network Conguration page is
displayed.
11 If Use DHCP for CMC Network Interface IP Address is enabled, do one of the following:
• Select Use DHCP to Obtain DNS Server Addresses to enable the DHCP server to obtain the DNS server addresses
automatically.
• Manually congure a DNS server IP address by leaving the Use DHCP to Obtain DNS Server Addresses check box unchecked
and then typing your primary and alternate DNS server IP addresses in the elds provided.
12 Click Apply Changes.
The Active Directory settings for extended schema is congured.
Conguring Active Directory With Extended Schema Using RACADM
To congure a CMC Active Directory with Extended Schema by using the RACADM commands, oen a command prompt and enter the
following commands at the command prompt:
racadm config -g cfgActiveDirectory -o cfgADEnable 1
racadm config -g cfgActiveDirectory -o cfgADType 1
racadm config -g cfgActiveDirectory -o cfgADRacName <RAC common name>
racadm config -g cfgActiveDirectory -o cfgADRacDomain < fully qualified rac domain name >
racadm config -g cfgActiveDirectory -o cfgADDomainController1 < fully qualified domain name or
IP Address of the domain controller >
racadm config -g cfgActiveDirectory -o cfgADDomainController2 < fully qualified domain name or
IP Address of the domain controller >
racadm config -g cfgActiveDirectory -o cfgADDomainController3 < fully qualified domain name or
IP Address of the domain controller >
NOTE
: You must congure at least one of the three addresses. CMC attempts to connect to each of the congured addresses
one-by-one until it makes a successful connection. With Extended Schema, these are the FQDN or IP addresses of the domain
controllers where this CMC device is located.
144 Conguring User Accounts and Privileges
