Reference Guide

– BOOT : BOOT Control
– SSD : PCIe SSD
– IOV : IO Virtualization
– PR : Part Exchange
– SWU : Software Change
– USR : User Tracking
– PDR : Physical Disk
– VDR : Virtual Disk
– SWC : Software Config
– DKM : Dell Key Mngr
– NDR : NIC OS Driver
– RAC : RAC Event
– ASR : Auto Sys Reset
– HWC : Hardware Config
– RRDU : IDSDM Redundancy
– AMP : Amperage
– VLT : Voltage
– DH : Cert Mgmt
– TMP : Temperature
– VME : Virtual Media
– ITR : Intrusion
– BAR : Backup/Restore
– PWR : Power Usage
– VFLA : vFlash Absent
– BIOS : BIOS Management
– LC : Lifecycle Contr
– FAN : Fan Event
– SEC : Security Event
NOTE: To view or export the Chassis log, only the CMC Login User privilege is required.
Example
• Display the number of records present in the Chassis Log:
racadm chassislog view -i
• Display the records under the storage category with severity set to warning:
racadm chassislog view -c storage -s warning
• Display the records under storage and system categories with severities set to warning or
critical:
racadm chassislog view -c storage,system -s warning,critical
• Display the records having severities set to warning or critical, starting from sequence number
4:
racadm chassislog view -s warning,critical -q 4
• Display 5 records starting from sequence number 20:
racadm chassislog view -q 20 -n 5
• Display all records of events that have occurred between 2011-01-02 23:33:40 and 2011-01-03
00:32:15:
racadm chassislog view -r "2011-01-02 23:33:40" -e "2011-01-03
00:32:15"
• Display all the available records from the active Chassis log:
racadm chassislog view -n all
• Display the last 25 records from the Chassis log:
racadm chassislog view
