Reference Guide

cfgChassisDefaultPowerCapLowerBoundBTU(Read Only)
Description Indicates the minimum default value to which you can set the
power cap of a chassis.
Legal Values Zero Watt
Default Zero Watt
cfgChassisPowerCap (Read/Write)
Description Indicates the maximum power consumption limit (in Watt) for
the entire chassis. The command generates an error if server
throttling is necessary to achieve the power goal based on the
value for this setting.
Legal Values 2715 – 16685 Watt
Default 16685 Watt
cfgChassisPowerCapF (Read/Write)
Description Indicates the maximum power consumption limit (in Watt) for
the entire chassis. Use cfgChassisPowerCapF when power
consumption is to be changed regardless of whether server
throttling is required. This command generates an error if the
value for this setting is lower than the minimum power required
for the chassis configuration.
Legal Values 2715 – 16685 Watt
Default 16685 Watt
cfgChassisPowerCapFBTU (Read/Write)
Description
Indicates the maximum power consumption limit (in BTU/hr) for
the entire chassis. Use cfgChassisCapFBTU when power
consumption is to be changed regardless of whether server
throttling is required. The command generates an error if the
value for this setting is lower than the minimum power required
for the chassis configuration.
Legal Values 9264 - 56931 BTU/hr
Default 56931 BTU/hr
cfgChassisPowerCapPercent (Read or Write)
Description
Indicates the power consumption limit as a percentage. The
percentage is computed mathematically as the minimum power
+ (percent * (maximum power - minimum power)). The
command generates an error if server throttling is necessary to
achieve the power goal based on the value for this setting.
Legal Values 16 -100
NOTE: If the specified percent is lower than the
minimum value, the CMC will set the value to the
minimum value.
Default 100
139
