Reference Guide

Clear Logs 0x00000008
Execute Server Control Commands 0x00000010
Access Virtual Console 0x00000020
Access Virtual Media 0x00000040
Test Alerts 0x00000080
Execute Debug Commands 0x00000100
cfgChassisPower
This group is applicable only to CMC and contains parameters to display or configure power for the chassis.
Use this object with the config or getconfig subcommands.
To use this object property, you must have the Chassis Configuration Administrator privilege.
The following sections provide information about the objects in the cfgChassisPower group.
NOTE: While configuring chassis power from a file, update the value for one chassis power cap property and remove the
values for the other chassis power cap properties or, update the last percentage value as it is applicable to all chassis
power cap properties. The chassis power cap properties are: cfgChassisPowerCap, cfgChassisPowerCapF,
cfgChassisPowerCapBTU, cfgChassisPowerCapFBTU, cfgChassisPowerCapPercent, and
cfgChassisPowerCapFPercent.
cfgChassisInPower (Read Only)
Description
Indicates the cumulative input power consumption data (in Watt and BTU/hr) captured from
all healthy and functional PSUs in the chassis.
Legal Values None
Default None
cfgChassisPeakPower (Read Only)
Description
Indicates the maximum system input power consumption (in
Watt).
Legal Values
Default
cfgChassisPeakPowerTimestamp (Read Only)
Description
The timestamp recorded when the peak input power
consumption value occurred.
Legal Values
Default
cfgChassisMinPower (Read Only)
Description
The minimum system input power consumption value (in Watt) over the time since the value
was last cleared.
Legal Values None
Default None
