Reference Guide

cfgLDAPBindpassword (Write Only)
Description A bind password to use in conjunction with the bindDN. The bind password is sensitive data,
and should be protected. This is optional but is required if anonymous bind is not supported.
Legal Values String. Maximum length = 254
Default Null
cfgLDAPSearchFilter (Read/Write)
Description A valid LDAP search filter. This is used if the user attribute
cannot uniquely identify the login user within the chosen
baseDN. The search filter only applies to userDN search and not
the group membership search.
Legal Values
String of maximum length = 1024 characters
Default (objectclass=*)
Searches for all objects in tree.
cfgLDAPCertValidationEnable (Read/Write)
Description Controls certificate validation during SSL handshake.
Legal Values
• 1 (TRUE)—CMC uses the CA certificate to validate the
LDAP server certificate during SSL handshake.
• 0 (FALSE)—CMC does not performthe certificate validation
task of SSL handshake.
Default 1
cfgLDAPNetworkTimeout
Description
Configures the network timeout in seconds.
Legal Values Positive integer
Default 30 seconds
cfgLDAPSearchTimeout
Description
Configures the search timeout in seconds.
Legal Values Positive integer
Default 120 seconds
cfgLDAPSRVLookupDomainName
Description
Configures the domain name to be used in the SRV lookup.
Legal Values String of maximum length of 254 alphanumeric characters and
hyphens. The string must begin with a letter.
Default [null]
133
