Reference Guide

cfgLDAPBasedn (Read/Write)
Description The Domain Name of the branch of the directory where all
searches should start from.
Legal Values String. Maximum length = 254
Default Null
cfgLDAPUserAttribute (Read/Write)
Description Specifies the user attribute to search for. It is recommended to
be unique within the chosen baseDN, otherwise a search filter
must be configured to make sure the uniqueness of the login
user. If the userDN cannot be uniquely identified, login fails with
error.
Legal Values String. Maximum length = 254
Default Null
uid if not configured.
cfgLDAPGroupAttribute (Read/Write)
Description Specifies which LDAP attribute is used to check for group
membership. This should be an attribute of the group class. If
not specified, then CMC uses the member and unique member
attributes.
Legal Values String. Maximum length = 254
Default Null
cfgLDAPGroupAttributeIsDN (Read/Write)
Description
If enabled, the CMC performs DN matching; otherwise, the
CMC uses the username provided at login for matching.
Legal Values
• 1 (TRUE)—Use the userDN from the LDAP Server
• 0 (FALSE)—Use the userDN provided by the login user
Default 1
cfgLDAPBinddn (Read/Write)
Description
The distinguished name of a user used to bind to the server
when searching for the login user's DN. If not provided, an
anonymous bind is used. This is optional but is required if
anonymous bind is not supported.
NOTE: If cfgLDAPBindDN is [null] and
cfgLDAPBindPassword is [null], then the CMC attempts
an anonymous bind.
Legal Values String. Maximum length = 254
Default Null
132
