Reference Guide

cfgSsnMgtRacadmTimeout (Read/Write)
Description Defines the idle timeout in seconds for the Remote RACADM interface. If a remote RACADM session remains
inactive for more than the specified timeout, the session is automatically ended.
Legal Values 0, 10 –1920
Default iDRAC - 60
CMC - 30
Example
racadm getconfig -g cfgSessionManagement cfgSsnMgtWebserverTimeout=0
cfgSsnMgtTelnetIdleTimeout=0
cfgSsnMgtSshIdleTimeout=300
cfgSsnMgtRacadmTimeout=0
cfgSsnMgtWebserverTimeout (Read/Write)
Description Defines the Web server time-out. This property sets the amount of time (in seconds) that
a connection is allowed to remain idle (there is no user input). The session is cancelled if
the time limit set by this property is reached. Changes to this setting do not affect the
current session. You must log out and log in again to make the new settings effective.
An expired Web server session logs out the current session.
Legal Values 60 – 10800
Default 1800
cfgSerial
This group contains configuration parameters for CMC services. One instance of the group is allowed.
Use this object with the getconfig or config subcommands.
To use this object property, you must have the Chassis Configuration Administrator privilege.
The following sections provide information about the objects in the cfgSerial group.
NOTE: The cfgSerial object group is applicable for iDRAC Enterprise on server modules for only two properties—
cfgSerialTelnetEnable=1 and cfgSerialSshEnable=1.
cfgSerialBaudRate (Read/Write)
Description
Sets the baud rate on the serial port.
Legal Values
2400, 4800, 9600, 19200, 28800, 38400, 57600,115200
Default
115200
cfgSerialConsoleEnable (Read/Write)
Description
Enables or disables the RAC or CMC serial console interface.
Legal Values
• 1 (TRUE)
• 0 (FALSE)
Default
1
