Reference Guide

iDRAC Specific User Privilege Privilege Bit Mask
Fabric C Administrator 0x0000800
Examples
The following table provides sample privilege bit masks for users with one or more privileges.
User Privileges Privilege Bit Mask
The user is not allowed to access CMC. 0x00000000
The user may only log in to CMC and view CMC and server
configuration information.
0x00000001
The user may log in to CMC and change configuration. 0x00000001 + 0x00000002 = 0x00000003
The user may log in, access Virtual Media, and Virtual Console. 0x00000001 + 0x00000040 + 0x00000080 =
0x000000C1
cfgUserAdminUserName (Read/Write)
Description The name of the user for this index. The user index is created by
writing a string into this name field if the index is empty. Writing
a string of double quotation marks ("") deletes the user at that
index. You cannot change the name. You must delete and then
recreate the name. The string cannot contain / (forward slash),
\ (backslash), . (period), @ (at symbol) or quotation marks.
NOTE: This property value must be unique among user
names.
Legal Values A string of up to 16 ASCII characters.
Default
• root (User 2)
• <blank> (All others)
cfgUserAdminPassword (Write Only)
Description
The password for this user. User passwords are encrypted and cannot be seen or displayed
after the property is written.
Legal Values A string of up to 20 ASCII characters.
Default ********
cfgUserAdminEnable (Read/Write)
Description
Enables or disables an individual user.
NOTE: You can enable a user for a given index, only if you set the password for the
same user.
Legal Values
• 1 (TRUE)
• 0 (FALSE)
Default
0
cfgEmailAlert
This group contains parameters to configure e-mail alerting capabilities. Up to four instances of this group are allowed.
Use this object with the getconfig and config subcommands.
112
