Reference Guide

NOTE: This parameter is only configurable if the cfgNicUseDhcp parameter is set to
0 (FALSE).
Legal Values String representing a valid gateway IPv4 address. For example: 192.168.0.1.
Default 192.168.0.1
cfgNicMacAddress (Read Only)
Description The CMC NIC MAC address in the format: dd:dd:dd:dd:dd:dd,
where d is a hexadecimal digit in range 0 - 9, A - F
Legal Values String representing CMC NIC MAC address.
Default The current MAC address of CMC NIC. For example,
00:12:67:52:51:A3.
cfgRemoteHosts
This group provides properties that allow configuration of the SMTP server for e-mail alerts.
This group enables/disables and configures firmware updates, NTP, remote syslogging, and SMTP email alerting.
Use this object with the config or getconfig subcommands.
To use this object property, you must have Chassis Configuration Administrator privilege.
The following sections provide information about the objects in the cfgRemoteHosts group.
cfgRhostsFwUpdateTftpEnable (Read/Write)
Description
Enables or disables CMC firmware update from a network TFTP
server.
Legal Values
• 1 (TRUE)
• 0 (FALSE)
Default 1
cfgRhostsFwUpdateIpAddr (Read/Write)
Description
Specifies the network TFTP server IPv4 or IPv6 address that is
used for TFTP CMC firmware update operations.
Legal Values A string representing a valid IPv4 or IPv6 address. For example,
192.168.0.61
Default For IPv4, it is 0.0.0.0
cfgRhostsFwUpdatePath (Read/Write)
Description
Specifies TFTP path where CMC firmware image file exists on
the TFTP server. The TFTP path is relative to the TFTP root
path on the TFTP server.
NOTE: The server may still require you to specify the
drive (for example, C:).
Legal Values A string with a maximum length of 255 ASCII characters.
Default <blank>
107
