Reference Guide

idRacBuildInfo (Read Only)
Description String containing the current RAC firmware build version.
Legal Values A string of up to 16 ASCII characters.
Default for CMC The current CMC firmware build version.
idRacName (Read Only)
Description A user-assigned name to identify this controller.
Legal Values A string of up to 15 ASCII characters.
Default for CMC CMC
cfgLanNetworking
This group contains parameters to configure NIC for IPv4.
One instance of the group is allowed. Some objects in this group may require iDRAC NIC to be reset, which may cause a brief loss in
connectivity. Objects that change iDRAC NIC IP address settings close all active user sessions and require users to reconnect using
the updated IP address settings.
Use this object with the config or getconfig subcommands.
To use this object property, you must have the Chassis Configuration Administrator privilege.
NOTE: You can configure any setting that is not preceded by the hash sign (#) in the output. To modify a configurable
object, use the -o option.
The following sections provide information about the objects in the cfgLanNetworking group.
cfgNicIPv4Enable (Read or Write)
Description
Enables or disables the IPv4 stack.
Legal Values
• 1 (TRUE)
• 0 (FALSE)
Default 0
cfgNicVLanId (Read or Write)
Description
Specifies the VLAN ID for the network VLAN configuration (in
CMC for iDRAC Enterprise on server modules). This property is
only valid if cfgNicVLanEnable is set to 1 (enabled).
Legal Values 1 – 4000 and 4021 – 4094
Default 1
Example
racadm config -g cfgLanNetworking -o
cfgNicVlanID
1
cfgDNSDomainNameFromDHCP (Read/Write)
Description
Specifies that the DNS domain name should be assigned from
the network DHCP server.
Legal Values
• 1 (TRUE)
103
