Reference Guide

3
CMC Property Database Group and Object
Descriptions
The CMC property database contains the configuration information for CMC. Data is organized by associated object, and objects
are organized by object group. The IDs for the groups and objects that the property database supports are listed in this section for
CMC.
Use the group and object IDs with the RACADM subcommands to configure CMC.
NOTE: You can configure any setting that is not preceded by the hash sign (#) in the output. To modify a configurable
object, use the -o option.
NOTE: To view a list of groups that you can use with the database objects, run the command. The -h, or help option,
displays a list of all available configuration groups in alphabetical order. This option is useful when you do not have exact
group names.
NOTE: RACADM sets the value of objects without performing any functional validation on them. For example, RACADM
allows you to set the Certificate Validation object to 1 with the Active Directory object set to 0, even though Certificate
Validation can happen only if Active Directory is enabled. Similarly, the cfgADSSOEnable object can be set to 0 or 1 even
if the
cfgADEnable object is 0, but it takes effect only if Active Directory is enabled.
All string values are limited to displayable ASCII characters, except where otherwise noted.
idRacInfo
This group contains display parameters to provide information about the specifics of CMC being queried. One instance of the group
is allowed.
Use this object with the getconfig subcommand.
To use this object, you must have CMC Login User privilege.
The following sections provide information about the objects in the idRACInfo group.
idRacProductInfo (Read Only)
Description
A text string that identifies the product.
Legal Values A string of up to 63 ASCII characters.
Default for iDRAC Integrated Dell Remote Access Controller.
Default for CMC Chassis Management Controller.
idRacVersionInfo (Read Only)
Description
String containing the current product firmware version.
Legal Values A string of up to 63 ASCII characters.
Default The current version number.
102
