Reference Guide

• Verifies if the required system resources are available.
• Validates Active Directory configuration.
• Verifies if the SSL certificate and certificate signing request
(key) exists.
• Acquires LDAP and Global Catalog Service records from
DNS.
• Verifies if the CMC can acquire CMC, LDAP and Global
Catalog servers FQDN through reverse IP lookups.
• Verifies that the CMC principal name matches the principal
name in the uploaded Keytab file.
• Verifies that the CMC acquires a Kerberos TGT.
• Acquires user privileges from the Active Directory server.
• Checks the time to acquire user privileges with the allotted
time to login.
NOTE: In the event of an error, the command outputs all
tests performed up to and including the test that failed,
and all the error messages.
Synopsis
testfeature -f adkrb -u <username> [-d
<diagnostic-message-level>]
testfeature -f ldap
Description Tests LDAP configuration and operation, and reports success as
each stage of the authentication process proceeds. After
successful completion, this command prints the CMC privileges
assumed by the specified <username>.
If a failure occurs, the command stops with an error message
that displays the required corrective action. Use the optional -d
switch to obtain additional diagnostic information, as needed.
Synopsis
testfeature -f ldap -u <username> -p
<password>
[-d <diagnostic-message-level>]
testtrap
Description
Tests the RAC’s SNMP trap alerting feature by sending a test trap from iDRAC to a specified
destination trap listener on the network.
To use this subcommand, you must have the Test Alerts privilege.
NOTE: Before you execute the testtrap subcommand, make sure that the specified index
in the RACADM cfgAlerting group is configured properly.
Synopsis
racadm testtrap -i <index>
Input -i — Specifies the index of the trap configuration to be used for the test. Valid values are from 1 to
4.
Example
Commands for the cfgIpmiPet group:
• Enable the alert
racadm config -g cfgIpmiPet -o cfgIpmiPetAlertEnable -i 1
• Set the destination e-mail IP address
racadm config -g cfgIpmiPet -o cfgIpmiPetAlertDestIpAddr -i 1
192.168.0.110
• View the current test trap settings
racadm getconfig -g cfgIpmiPet -i <index>
