Quick Reference Guide

32 RACADM Subcommands
Example
$ feature -s
Feature Name = FlexAddress
Date/time Activated = 23 Jul 2009 - 21:01:10
Feature installed from SD-card SN =
TEST0123456789012345678
fwupdate
NOTE: To use this subcommand, you must have Chassis Configuration
Administrator privilege.
Description
Updates the firmware on the iKVM, primary CMC, standby CMC, server
iDRACs, or an IOM infrastructure device. This subcommand also performs
updates to the iDRAC firmware (if the CMC firmware version is 2.0 or later
and the iDRAC firmware version is 1.4) when the existing firmware is
corrupted.
NOTE: Running the fwupdate subcommand to update the firmware on the primary
CMC resets the primary CMC causing all network connections to be dropped.
During update of all other modules, including the standby CMC, the primary CMC
continues to run normally without resetting.
Usage
For local RACADM:
racadm fwupdate -g -u -a <
tftp server ip address > -d
<
path > [-m < module >]
racadm fwupdate -f <
ftp server ip address > < username >
<
password > -d < path > [-m < module >]
racadm fwupdate -u -m iominf-<n>
racadm fwupdate -s [-m <
module >]
racadm fwupdate -c [-m <
module >]
For remote RACADM:
