Using the LCD Panel Interface 181
The information in Table 4-15 is dynamically updated. If the server does not
support this feature, then the following information does not appear, else
Server Administrator options are as follows:
• Option “None” = No strings must be displayed on the LCD.
• Option “Default” = No Effect.
• Option “Custom” = Allows you to enter a string name for the server.
The information is displayed only if iDRAC has finished booting.
IP4 Address:
<address,
acquiring>
Only displays if IPv4 is enabled.
IP6 <enabled,
disabled>
Only displays if iDRAC supports IPv6. Displays current IPv6-
enabled state.
IP6 Local Address:
<address>
Only displays if iDRAC supports IPv6. Only displays if IPv6 is
enabled.
IP6 Global Address:
<address>
Only displays if iDRAC supports IPv6. Only displays if IPv6 is
enabled.
FlexAddress enabled
on Fabrics
Only displays if the feature is installed. Lists the fabrics
enabled for this server (that is, A, B, C).
Table 4-15. Server Status (continued)
Item Description
