Quick Reference Guide

180 Using the LCD Panel Interface
Error Messages If no error then "No Errors" is shown; otherwise error
messages are listed, critical errors first, then warnings.
Status Off or On
Model/Manufacture A description of the iKVM model.
Service Tag The factory-assigned service tag.
Part Number The manufacturer part number.
Firmware Version The iKVM firmware version.
Table 4-15. Server Status
Item Description
Example: Server 1,
Server 2, etc.
Name/Location
No Errors If no errors occur then No Errors is displayed, else lists error
messages (see "LCD Error Messages"). Lists critical errors first,
then warnings.
Slot Name Chassis slot name. For example, SLOT-01.
NOTE: You can set this through the CMC CLI or Web GUI.
Name User settable name of the server. You can set this through Dell
OpenManage. Only displays if iDRAC has finished booting,
and the server supports this feature, else displays iDRAC
booting messages.
Model Number Displays if iDRAC finished booting.
Service Tag Displays if iDRAC finished booting.
BIOS Version Server BIOS firmware version.
Last POST Code Displays the last BIOS POST code.
iDRAC Firmware
Version
Displays if iDRAC finished booting.
NOTE: iDRAC version 1.01 is displayed as 1.1. There is no iDRAC
version 1.10.
IP4 <enabled,
disabled>
Displays the current IPv4 enabled state.
Table 4-14. iKVM Status (continued)
Item Description
