Quick Reference Guide

18 RACADM Subcommands
setniccfg -- modify network configuration properties
setractime -- set the time on the CMC
setslotname -- sets the name of the slot in the chassis
setsysinfo -- set the chassis name and chassis location
sslcertview -- display a CA/server certificate in the CMC
sslcsrgen -- generate a certificate CSR from the CMC
testemail -- test CMC e-mail notifications
testfeature -- test CMC feature x
testtrap -- test CMC SNMP trap notifications
traceroute -- determine the route of a packet
traceroute6 -- determine the route of a packet
Example for racadm ? <command>
racadm ? getsysinfo
getsysinfo -- display general CMC and system information
Usage:
racadm getsysinfo [-d] [-c] [-A] [-4] [-6]
-----------------------------------------------------------
Valid Options:
-d : show CMC information
-c : show chassis information
-A : do not show headers or labels
-4 : show CMC IPv4 information
-6 : show CMC IPv6 information
arp
NOTE: To use this subcommand you must have Administrator privilege.
Description
Displays the Address Resolution Protocol (ARP) table. This table stores the
mapping of IP numbers to MAC addresses of the NICs in the chassis.
Example
• racadm arp
Address HWtype HWaddress Flags Mask Iface
143.166.152.3 ether 00:07:84:A7:CE:BC C eth0
143.166.152.2 ether 00:07:84:7B:9F:FC C eth0
143.166.152.1 ether 00:00:0C:07:AC:0A C eth0
