Quick Reference Guide

Using the LCD Panel Interface 179
Error Messages If no error then "No Errors" is shown; otherwise error messages
are listed, critical errors first, then warnings.
RPM Current fan speed in RPM
Table 4-12. PSU Status
Item Description
Name/Location Example: PSU1, PSU2, etc.
Error Messages If no error then "No Errors" is shown; otherwise error
messages are listed, critical errors first, then warnings.
Status Offline, Online, or Standby
Maximum Wattage Maximum Wattage that PSU can supply to the system
Table 4-13. IOM Status
Item Description
Name/Location Example: IOM A1, IOM B1. etc.
Error Messages If no error then "No Errors" is shown; otherwise error
messages are listed, critical errors first, then warnings.
Status Off or On
Model Model of the IOM
Fabric Type Networking type
IP address Only shows if IOM is On. Will be all zero for a pass through
type IOM.
Service Tag The factory-assigned service tag.
Table 4-14. iKVM Status
Item Description
Name iKVM
Table 4-11. Fan Status (continued)
Item Description
