Quick Reference Guide

Using the LCD Panel Interface 177
LCD Module and Server Status Information
The tables in this section describe status items that are displayed on the front
panel LCD for each type of component in the chassis.
Critical LinkT/ FlexAddr: Link Tuning
sensor, device option ROM failed
to support link tuning or flex
address (Mezz XX) was asserted
PCI device Option ROM for a NIC
does not support link tuning or the
FlexAddress feature.
Critical LinkT/ FlexAddr: Link Tuning
sensor, failed to program virtual
MAC address (<location>) was
asserted
BIOS failed to program virtual
MAC address on the given NIC
device.
Critical I/O Fatal Err: Fatal IO Group
sensor, fatal IO error (<location>)
Generated in association with a
CPU IERR and indicates which
device caused the CPU IERR.
Warning PCIE NonFatal Er: Non Fatal IO
Group sensor, PCIe error
(<location>)
Generated in association with a
CPU IERR.
Table 4-9. CMC Status
Item Description
Example: CMC1,
CMC2
Name/Location
No Errors If no error occurs then “No Errors” is displayed, else lists error
messages.
Firmware Version Only displays on an active CMC. Displays Standby for the
standby CMC.
IP4 <enabled,
disabled>
Displays current IPv4 enabled state only on an active CMC.
IP4 Address:
<address,
acquiring>
Only displays if IPv4 is enabled only on an active CMC.
Table 4-8. Server Status Screen (continued)
Severity Message Cause
