Front Panel LCD Messages
This section contains two subsections that list error and status information
that is displayed on the front panel LCD.
Error messages on the LCD have a format that is similar to the System Event
Log (SEL) viewed from the CLI or Web interface. The format is as follows:
<Severity> <Sensor Name>: <Sensor Type> sensor for
<Entity>, <Description of event>
The tables in the error section list the error and warning messages that are
displayed on the various LCD screens and the possible cause of the message.
Text enclosed in angled brackets (< >) indicates that the text may vary.
Status information on the LCD includes descriptive information about the
modules in the chassis. The tables in this section describe the information
that is displayed for each component.
Blank LCD and LED off The front panel circuit
board cable or the I/O
panel cable are not
connected properly; or one
or both are faulty.
Review the hardware log
using the GUI or RACADM
commands. Look for
messages that state:
Control Panel FPC
Cable: Cable sensor
for Control Panel,
configuration error
was asserted
Control Panel I/O
Cable: Cable sensor
for Control Panel,
configuration error
was asserted
Check that the cables are
connected properly.
Symptom Issue Recovery Action
