Quick Reference Guide

CMC Property Database Group and Object Definitions 135
cfgOobSnmpAgentCommunity
Sets the community string (identical to the community name) used for
authentication. The community string acts as a password shared between
different hosts over the network. This community string value must match
with that of the other hosts for any kind of communication through SNMP.
Example
racadm getconfig -g cfgOobSnmp
cfgOobSnmpTrapsEnable=1
cfgOobSnmpAgentCommunity=public
cfgTraps
NOTE: Use this object with the config or getconfig subcommands.
NOTE: To use this object property, you must have Chassis Configuration
Administrator privilege.
NOTE: You can configure any setting that is not preceded by the hash sign (#) in the
output. To modify a configurable object, use the -o option.
Description
Displays information for and configures delivery of SNMP traps for a specific
user.
# cfgTrapsIndex
Read only. Indicates the unique index of an alert instance.
cfgTrapsEnable
Enables or disables event traps on the CMC.
Configuration options: 1 (true), 0 (false)
cfgTrapsAlertDestIpAddr
Sets the IP address that will receive the alert.
Configuration options: A string representing a valid IP address. For example,
192.168.0.20.
