cfgNetTuningNicAutoneg
Enables auto-negotiation of physical link speed and duplex. When enabled,
auto-negotiation takes priority over values set in the cfgNetTuningNicSpeed
and cfgNetTuningNicFullDuplex objects. Configuration options: 1
(enabled), 0 (disabled)
Default: 1
Example
racadm getconfig -g cfgNetTuning
cfgNetTuningNicSpeed=100
cfgNetTuningNicFullDuplex=1
cfgNetTuningNicMtu=1500
cfgNetTuningNicAutoneg=1
cfgOobSnmp
NOTE: Use this object with the config or getconfig subcommands.
NOTE: To use this object property, you must have Chassis Configuration
Administrator privilege.
NOTE: You can configure any setting that is not preceded by the hash sign (#) in the
output. To modify a configurable object, use the -o option.
Description
Enables or disables the SNMP agent for the CMC. The CMC SNMP agent
supports the standard RFC1213 mib-2, and the Dell™ enterprise-specific
MIB.
cfgOobSnmpAgentEnable
Enables or disables the SNMP agent in the CMC.
• Configuration options: 1 (true), 0 (false)
•
Default: 0
