Quick Reference Guide

130 CMC Property Database Group and Object Definitions
Example
racadm getconfig -g cfgSessionManagement [-m server-
<n>] -o <object name> <object value>
cfgSsnMgtWebserverTimeout=0
cfgSsnMgtTelnetIdleTimeout=0
cfgSsnMgtSshIdleTimeout=300
cfgSsnMgtRacadmTimeout=0
cfgSerial
NOTE: Use this object with the config or getconfig subcommands.
NOTE: To use this object property, you must have Chassis Configuration
Administrator privilege.
Description
Displays information for and configures serial parameters.
Objects
cfgSerialBaudRate
Sets the baud rate on the CMC serial port.
• Configuration options: 2400, 4800, 9600, 19200, 28800, 38400, 57600,
115200
•
Default: 115200
cfgSerialConsoleEnable
Enables or disables the CMC serial console interface.
• Configuration options: 1 (true), 0 (false)
•
Default: 1
cfgSerialConsoleQuitKey
Specifies the key or key combination that terminates the serial text console.
The value can be represented by one of the following:
• Decimal value — For example: 95
