Quick Reference Guide

122 CMC Property Database Group and Object Definitions
cfgRhostsFwUpdateIpAddr
Specifies the IP address of the network TFTP server that has the CMC
firmware image.
Configuration options: A string representing a valid TFTP server IP address.
For example, 192.168.0.55.
Default: 0.0.0.0
cfgRhostsFwUpdatePath
Specifies the TFTP path where the CMC firmware image file exists on the
TFTP server. The TFTP path is relative to the TFTP root path on the TFTP
server.
NOTE: The server may still require you to specify the drive (for example, C).
Legal value: String of up to 255 characters.
cfgRhostsSmtpServerIpAddr
Specifies the IP address of the network SMTP server, which transmits email
alerts from the CMC if the alerts are configured and enabled.
Legal value: A string representing a valid SMTP server IP address. For
example, 192.168.0.55.
Default: localhost.localdomain
cfgRhostsNtpEnable
Enables or disables the use of the Network Time Protocol (NTP) for date and
time synchronization.
• Configuration options: 1 (true), 0 (false)
•
Default: 0
cfgRhostsNtpServer1
Specifies the first of three possible NTP servers.
Legal value: A string representing a valid NTP server. For example,
ntp1.ntp.net. At least one NTP server must be specified; duplicate entries are
not allowed.
Default: [null]
