Quick Reference Guide

116 CMC Property Database Group and Object Definitions
cfgIPv6LanNetworking
NOTE: Use this object with the config or getconfig subcommands.
NOTE: To use this object property, you must have Chassis Configuration
Administrator privilege.
Description
Displays information for and configures IPv6 network-related properties. Use
the -m option to apply this setting to the iDRAC.
cfgIPv6Enable
Enables or disables IPv6 on the CMC. If the property is set to 0 (false), the
remote network interfaces to the CMC are not accessible over IPv6.
• Configuration options: 1 (true), 0 (false)
•
Default: 0
cfgIPv6AutoConfig
Enables or disables IPv6 auto configuration. If this value is set to 0, the CMC
disables auto configuration and statically assigns IPv6 addresses. If this value
is set to 1, the CMC obtains address and route information using stateless
auto configuration and DHCPv6.
NOTE: The CMC uses its MAC address for its DUID (DUID-LL) when communicating
with a DHCPv6 server.
• Configuration options: 1 (true), 0 (false)
•
Default: 1
cfgIPv6Address
Assigns a static IPv6 address to the CMC. This property is used only if
cfgIPv6AutoConfig is set to 0 (false).
• Legal value: A string representing a valid IPv6 address. For example,
2001:DB8:1234:5678:9ABC:DE11:C00C:BEEF
•
Default: ::
