Quick Reference Guide

114 CMC Property Database Group and Object Definitions
• Configuration options: A string representing a valid IP address, for
example: 192.168.0.20.
•
Default: 0.0.0.0
NOTE: cfgDNSServer1 and cfgDNSServer2 may be set to identical values while
swapping addresses.
cfgDNSRacName
Displays the CMC name. This parameter is used only if cfgDNSRegisterRac
is set to 1 (true).
• Configuration options: String of up to 63 alphanumeric characters and
hyphens; must begin with a letter. For example:
cmc-1 , d-345 .
•
Default: cmc -< service tag >
cfgDNSDomainName
Displays the DNS domain name. This parameter displays only if
cfgDNSDomainNameFromDHCP is set to 0 (false).
• Configuration options: String of up to 254 alphanumeric characters and
hyphens;
must begin with a letter . For example: p45 , a-tz-1 , rid- .
•
Default: ""
cfgDNSDomainNameFromDHCP
Specifies whether the CMC DNS domain name is assigned by the network
DHCP server.
• Configuration options: 1 (true), 0 (false)
•
Default: 1
This property is used only if cfgNicUseDhcp is set to 1 (true), or if both
cfgIPv6Enable and cfgIPv6AutoConfig are set to 1 (true).
If all the following properties are set to 1 (true), the CMC can obtain its DNS
domain name from either a DHCP or DHCPv6 server. The network
administrator must ensure that the DHCP servers are configured to provide
the same DNS domain name to the CMC, otherwise the domain name
becomes unpredictable.
• cfgNicIPv4Enable
