验证 FlexAddress 激活
要查看 FlexAddress 功能的激活状态，请运行以下 RACADM 命令：
racadm featurecard -s
Feature Name = FlexAddress
Date/time Activated = 05 Oct 2013 - 11:50:49
Feature installed from SD-card serial number = CN0H871T1374036T00MXA00
Feature Name = FlexAddressPlus
Date/time Activated = 05 Oct 2013 - 11:50:49
Feature installed from SD-card serial number = CN0H871T1374036T00MXA00
Feature Name = ExtendedStorage
Current Status = redundant, active
Date/time Activated = 05 Oct 2013 - 11:50:58
Feature installed from SD-card serial number = CN0H871T1374036T00MXA00
如果机箱中没有活动的功能，则此命令将返回消息：racadm feature -s No features active on the chassis
racadm feature -s
No features active on the chassis
要查看 SD 卡信息：
$ racadm featurecard -s
Active CMC:
The feature card inserted is valid, serial number CN0H871T1374036T00MXA00
The feature card contains the following feature(s)
FlexAddress: bound
FlexAddressPlus: bound
ExtendedStorage: bound
表. 25: featurecard -s 命令返回的状态消息
状态消息 操作
No feature card inserted.
检查 CMC 以验证 SD 卡是否正确插入。
The feature card inserted is valid and
contains the following feature(s)
FlexAddress: bound.
无需任何操作。
The feature card inserted is valid and
contains the following feature(s)
FlexAddress: bound to another chassis,
svctag=ABC1234, SD card SN = 1122334455.
移除 SD 卡；找到当前机箱的 SD 卡并进行安装。
The feature card inserted is valid and
contains the following feature(s)
FlexAddress: not bound.
功能卡可以移到另一个机箱或在当前机箱上重新激活。要在当前机
箱上重新激活，请输入 racadm racreset，直到安装了功能卡
的 CMC 模块变为活动为止。
Dell 功能卡可含一个以上的功能。Dell 功能卡上包含的任意功能已在一个机箱上激活后，该 Dell 功能卡上可能包含的所有其他功能都
不能在其他机箱上激活。在这种情况下，racadm feature-s 命令会显示受到影响功能的以下消息：
ERROR: One or more features on the SD card are active on another chassis
有关 feature 和 featurecard 命令的更多信息，请参阅 适用于 PowerEdge FX2/FX2s 的 Dell Chassis Management Controller
RACADM
命令行参考指南 。
