Working with Running Sessions

Session Management 12-51

Figure 12-43 Assigning VLAN ID to VLAN Component

VLANGroup

The VLANGroup inventory property facilities you to provide VLAN IDs in a group. Creating groups for

VLAN IDs facilitates you to map your VLAN ID requirements with the existing group names, so as to

choose from a set of VLAN IDs as per your requirements.

The VLAN groups are created on a matrix switch. To create a VLAN ID group, you are required to define

the group name in curly brackets, and its corresponding VLAN IDs or ranges must be in parenthesis; for

example: {gp1}(20..25).

Note Groupname is associated with assettag and it is mandatory to select an asset tag before selecting a

value for VLANGroup.

Note You can associate only one group at a time with the VLAN component.

To assign a VLANGroup to the VLAN component, press Ctrl+spacebar and select the group name; see
