Working with Running Sessions

Session Management 12-39

Adding Resource Instances

To add resource instances, perform the following steps:

1. Open a session editor > Resource Instances view.

2. Drag a resource instance node into the session.

The outline is yellow, which indicates that the node has not yet been allocated to your session.

3. Enable interfaces.

4. Set the properties as required. Use the Configuration Files and Image Files tabs if you need

provisioning.

5. Save the session (File > Save).

The scheduler determines the best resource to be allocated and adds into the session. The resource

operations, such as Resource

Adapter setup methods, will be executed once the resource has been

allocated.

Note If the scheduler cannot allocate this resource for this session, the dependency manager will list all

sessions.

Substitution Resource Instances

Resource instances can be swapped or substituted as soon as a session is in a Confirmed or Running state.

To substitute resource instances, perform the following steps:

1. Open a Running or Confirmed session.

2. In the Template editor, select a resource instance, right-click and select Substitute.

The Resource Substitution dialog box displays with the Automatic Substitution Option selected by

default; see Figure 12-36.

Figure 12-36 Resource Substitution
