Working with Running Sessions

12-30 Active System Manager User Guide, Release 7.1

Figure 12-25 Tap

Link Feasibility Toolbar

The link feasibility icons (mutually exclusive) allow you to build connectivity within your Template while

being aware of your underlying physical connectivity and compatibility between interface types.

• Show Static or Switched Interfaces Only—To use this icon option, you must first select a resource

type or resource instance. Effectively, this option removes interfaces that are not connected via the

underlying infrastructure.

• Show Existing Physical Connectivity—Shows or hides all possible connectivity. Select one or more

of the drawn links and right-click Create Link.

Note To display current, possible connectivity, perform the following steps:

1. Select a resource instance and interface end point.

2. Right-click (or press F2) to display the Quick Connectivity dialog box.

3. Select an entry in the dialog box to author the resource and interface into the Template.
