Working with Templates
Template Management 11-53
Modifying Interface Properties
Note Only the attributes with values are shown in the interface—Properties view; the others are omitted.
To modify interface properties, display the interface Properties view and perform the following steps:
1. Display the interface Properties view.
For Resour
ce Type, you can modify the editable properties listed on the Interface, Inventory, and
Provisioning tabs.
For Resource Instance, you can modify the editable properties listed on the Interface and
Provisioning tabs.
2. On the Authoring tab, edit the Name field as appropriate.
3. On the Configuration tab, edit the property.
Managing Template Links
Authoring links essentially means to create connectivity (links) between or among the interfaces of the
resources. The following topics describe how to author links:
• Creating Links
• Defining Custom Attributes for Links
• Disabling and Enabling Template Links
Creating Links
You can only create a link for interfaces based on user preferences. If the preferences (Enable resource
interfaces on link creation check box is selected; see Figure 11-31 on page 11-51), you can link the
interfaces, even if some of the interfaces are disabled. If it is not selected, you cannot create links using
disabled interfaces.
Links have properties. By default, they are automatically named (for example, Link_n). Link names must
be unique. If you have 10 names, all links must have different names; if not, you cannot save the Template.
To display link properties, perform one of the following methods:
• In the link editor, select a link.
• In the Outline view, select a link.
IP Address Interface management port. Only available when a management port is selected.
IP Subnet Interface subnet associated with IP address. Only available when a management port is selected.
Gateway Gateway IP address. Only available when a management port is selected.
Provisioning List of all provisioning parameters that can be overwritten from their default value. For information
about setting up provisioning parameters, see Chapter 8, “Using Inventory.”
Table 11-9 Default Interface Properties for a Resource Instance (continued)
Tab Name
Property
Name Description
