Working with Templates

Template Management 11-25

Updating Templates using the Template Editor

Once you have created a blank Template, define the network configuration that you want to manage or test

by adding elements, such as resource types, resource instances, interfaces, properties, and connectivity. For

more details, see the following topics:

• Viewing and Modifying Template Properties

• Adding Resource Types

• Setting Resource Type Properties for Scheduling

• Deleting Resource Types

• Adding Resource Instances

• Deleting Resource Instances

• Modifying Resource Properties

• Defining Provisioning Policies

• Supporting Layer 2 Switching

• Using Annotations

Viewing and Modifying Template Properties

You can modify a variety of Template properties, including:

• Template-level properties for a specific Template

• Resource type-level and resource instance-level properties for the selected resource

• Interface-level properties for the selected interface

• Link properties for the selected link

To view the Template properties, select the Template in the editor background. Properties are typically

displayed when you first add an element type. You can display properties and later modify them.

Note If any properties are marked as Required by the administrator, the property value must be entered

before saving and scheduling the Template.
