Template Management 11-3
Template Types
The Active System Manager software supports the following three Template types; see Table 11-2.
Table 11-2 Template Types
Template Type Description
Normal Template The resources are selected from the free pool. By default, the Normal Template is selected.
Physical Template Provisions Hypervisors on raw blades. It is also used to provision the VLAN component with
a range of VLAN IDs onto matrix switch. In case of Physical Template, the Resource
Adapter internally makes clusters from Hypervisors.
Note The Physical and Logical Template types exist in the Active System Manager
software to provision ESXI image on raw blades, and use such Hypervisors to
provision VMs. This happens in the following two steps:
• Firstly, the Physical Template is created, and, during realization, the ESXI image is
provisioned on raw blades.
• Secondly, the Logical template is created to provision VMs on such Hypervisors, by
realizing the template onto session created from the Physical Template.
Logical Template The Logical template is used to provision VMs on Hypervisor or cluster, from sessions,
created from physical template. It is also used to provision the VLAN component from VLAN
range given in the Physical template
Physical Template
The workflow of Physical Template consists of the following tasks:
• Linking Editor
• Creating a Physical Template
• Creating Orchestration for Provisioning
• Scheduling Template to Create a Session
• Provisioning
Properties View Associated with the selections in the Template editor, link editor, and the Outline
view. The Properties view displays the properties of any of the selected objects in
the associated views or editor. In case of multiple selections, the property of the
object selected first will be displayed.
Table 11-1 Template Perspective Elements (continued)
View or Editor
Name
View or
Editor Description
