User's Manual

Note Network cannot be deleted if it is referenced as VMC configuration of a Server Profile Template.
Understanding Networks
Network Management 10-7
Editing an IP Address Range
1. On the Active System Manager navigation bar menu, click the Setup perspective.
2. On the Active System Manager toolbar, click the Networking perspective.
The Networking Configuration editor appears.
3. In the Configured Networks folder, click SAN iSCSI.
4. From the list of SAN iSCSI networks, select a network and click Edit.
5. On the Edit Network Configuration dialog box, click Edit IP Range.
6. Make your desired changes.
7. Click Save IP Range.
8. Click OK.
Deleting an IP Address Range
Note Attempting to delete an IP address range that includes addresses currently assigned to a resource
will cause an error.
1. On the Active System Manager navigation bar menu, click the Setup perspective.
2. On the Active System Manager toolbar, click the Networking perspective.
The Networking Configuration editor appears.
3. In the Configured Networks folder, click SAN iSCSI or Management network.
4. From the list of networks, select a network and click Edit.
5. On the Edit Network Configuration dialog box, select the IP range to delete, and click Delete IP
Range.
6. Click OK.
Naming Conventions when using Orchestrations
For each network created, the name of the network must contain one of the following strings:
• HypervisorManagement
• SANiSCSI
• Workload
• HyperVClusterPrivate
• vMotionLiveMigration
