User's Manual

Working with Resource Adapters
Repository Management 9-23
Figure 9-11 Operation Attributes
Table 9-12 lists and describes the operation attribute types as displayed in Figure 9-11.
Table 9-12 Operation Attribute Types
Attributes Description
Name Lists all parameters related to selected operation.
Type Lists parameter types as ‘String’, ‘Number’ or ‘Password’.
Note: In case of ‘Password’ type, all other attributes are deactivated i.e. other
attributes cannot be selected or edited except Mandatory, Editable and Common
attributes.
Default Value Allows to enter default parameter value.
Possible Values Allows to select value from a list of pre-defined possible values.
Unit Allows to enter unit value.
Mandatory Allows to select parameter as ‘Mandatory’.
Editable Allows to select the parameter as ‘Editable’.
Common Allows to select parameter as ‘Common’.
Value Source Allows you to select value from a list of pre-defined context-sensitive values.
Sub Type Allows you to select value from a list of pre-defined values based on Value Sources.
5. Optional. View or edit the methods: select one method to see associated detailed information and the
associated custom attributes definitions. You can update the information at will. Click File > Save to
save the new content of RA.
6. Optional. Remove a method: select a method and click Remove > File > Save to save the new RA
content.
7. Optional Add a method to the RA: click Add > a method type. Fill in the Operation Details and
attributes for this exposed method. Reference to the RA code (such as tcl files) must be present on the
Active System Manager server to be executed properly.
