Working with Resource Adapters
9-16 Active System Manager User Guide, Release 7.1
Working with Resource Adapters
In the Active System Manager system, resources—and therefore Resource Adapters (RAs)—are organized
into a couple of categories:
• Managed Resources—Explicitly specified in Template designs, scheduled by the users and set up and
configured in live or active sessions. Managed Resources may include switches, routers, servers and
SAN equipment. Examples of the types of control methods used for managed resources may include
operations such as Acquire Control, Discover Inventory, Send Command, Apply OS Image, Load
Configuration, Save Configuration or Reboot.
• Control Resources—Form what may be considered the control and connection plane of the
environment. These resources help create or realize the Template designs that are authored by the users.
Rather than being explicitly specified in Template designs, these resources work implicitly “behind the
scenes” to connect and configure the Managed Resources and to perform various control actions.
Control Resources may include physical layer switches (electrical or optical,) Layer 2 switches, power
controllers and terminal servers. Examples of the types of methods used for control resources may
include operations such as Acquire Control, Make Link, Break Link, Configure VLAN, Power On or
Power Off.
The Resource Adapter Framework (RAF) supports a wide range of protocols and methods including Telnet,
SSH, SNMP, Sockets, TL1, XML, HTTPs, SOAP, WSDL, CORBA and various TMF standards. Once
adapters are created using a Software Development Kit (SDK) they can simply be plugged-in to the Active
System Manager system, without any changes to the operating software.
The RAF is a fundamental element that provides flexibility and extensibility to the Active System Manager
architecture, and which enables Active System Manager to be used across a wide range of technologies and
applications.
Resource adapters are built using the Dell software development kit and can be deployed using the Active
System Manager application.
The following topics describe how to work with Resource Adapters:
• Opening the Resource Adapters View
• Opening the Resource Adapter Editor
• Deleting Resource Adapters
• Deleting Resource Adapters
• Editing Resource Adapters
• Exporting Resource Adapters
• Deleting Resource Adapters
