Understanding Resource Allocation
8-14 Active System Manager User Guide, Release 7.1
Understanding Resource Allocation
The Active System Manager software provides two views that are introduced in the Inventory perspective:
Resource Allocation view and Resource Port Allocation view.
The purpose of the Resource Allocation view is to understand the current resource allocation, at the
resource and port level. This view displays all allocations associated to a particular resource.
To access the Resource Allocation view, select one of the following methods:
• On the Active System Manager menu bar, click Window > Show View > Other > Active System
Manager > Resource Allocation > OK.
• In the Resource Instances view, right-click a resource instance and select Show Resource Allocation.
Features of the Resource Allocation view include:
• You can keep the content view synchronized with your resource selection in the Resource Instances
view: click the Link with a Resource Instances view icon, navigate to the Resource Instances view,
and select a resource. The resource allocation opens with the resource and all sessions where the
resource is currently in use.
• The standard calendar operations (switch, view, etc.) and sessions (extend, move, cancel) are allowed.
• This view is refreshed automatically on session or allocation changes.
The purpose of the Resource Port Allocation view is to display the selected resource with all ports, and for
each port, in which session the ports are being used.
To access the Resource Port Allocation view, select one of the following methods:
• On the Active System Manager menu bar, click Window > Show View > Other > Active System
Manager > Resource Port Allocation > OK.
• In the Resource Instances view, right-click a resource instance and select Show Port Allocation. The
resource allocation opens with the resource and all sessions where the resource is currently in use.
Features of the Resource Port Allocation view include:
• The standard calendar operations (switch, view, etc.) and sessions (extend, move, cancel) are allowed.
• This view is refreshed automatically on session or allocation changes.
