User's Manual

Using the Resource Allocation Calendar
Using Inventory 8-11
Using Links View Filters
The Active System Manager software includes four preset Links view filters:
• Managed to Managed (resource to resource links)—Displays the links created between two
managed resources.
• Managed to Control—Displays the links between the interface of a managed resource to the interface
of a control resource.
• Contr
ol to Managed—Displays the links between the interface of a control resource to the interface
of a managed resource.
• Contr
ol to Control—Displays the links created between two managed resources.
You can also create additional custom filters to determine if one resource is connected to another resource.
For example, to view everything connected to a matrix switch, create a filter containing the name or model
of the matrix switch.
When you apply a filter, synchronization automatically turns off, and vice versa.
Using the Search Function
You can also access your inventory via the built-in Active System Manager Search function.
Using the Resource Allocation Calendar
The Resource Allocation Calendar is a display option for the Resource Instances view that enables you to
view allocation of resources to sessions and their status.
To display the Resource Allocation Calendar view, perform the following steps:
1. On the Active System Manager menu bar, click Window > Show View > Other > Active System
Manager > Resource Instances.
2. In the top-right corner of the Resource Instances view, click the Show Calendar icon.
The Resource Allocation Calendar displays within the right-hand side of the view. All of the associated
sessions for each resource instance that are part of the session within the Resource Availability Calendar
display. The associated sessions for each resource instance appear as a colored rectangular bar.
This section describes the following topics:
• Using the Resource Availability Calendar Options
• Analyzing Resource Instance Availability in Existing Sessions
