Accessing Inventory

8-8 Active System Manager User Guide, Release 7.1

Both the Resource Types and Resource Instances views allow grouping; the Group By icon is available at

the top-right of the Resource Types and Resource Instances view menu bars.

Note For many Active System Manager users, your site’s custom properties may be the most relevant

properties for you to use while grouping and organizing your inventory.

Accessing Resources via the Filters Dialog Box

You can use a filter to modify the display of your inventory resources. Both the Resource Types and

Resource Instances views allow filtering. You use the Filters feature to specify filters that force the Active

System Manager application to only display the resource type and resource instance information that you

require within the associated views.

In general, you should set your resource types or resource instances filter to “Managed Equipment”,

because for most practical applications, almost all of your inventory is defined as “managed”.

To access the Filters dialog box, in the top-right part of an associated navigator view, click the Filters icon.

Figure 8-6 displays an example of Filters dialog box.

Figure 8-6 Filters Dialog Box

The Filters dialog box includes the following built-in filters (for Resource Types and Resource Instances

views only):

• Managed Equipment—The device under test (DUT) or equipment under test (EUT). Resources are

modeled by type, which are specifications by manufacturer and model that can be authored as generic

elements in templates, and by instance, which are specific resources with unique asset tags.

• Control Equipment—The infrastructure of the automated environment, including matrix switches

(Layer 1 or 2; electrical, optical, or virtual), power controllers, and terminal servers.

• Virtual Equipment—Available only on the Resource Instances view.

• VLAN Equipment—Available only on the Resource Instances view.

• Schedulable Equipment—Available only on the Resource Instances view.

• Equipment in Maintenance—Available only on the Resource Instances view.
