Server Template and Profiles 7-7
8. Select the network(s) to associate with this configuration. You can select one or more networks for a
LAN connection type, but only one network for SAN (iSCSI) or SAN (FCoE) connection types. Click
on Add to add a network.
9. Click OK.
Adding or Editing Boot Settings on a Server Template
The information entered on this page is used to filter the servers that will be displayed on the Server
Selection page of the Server Profile wizard when attaching a profile. Only servers that match the criteria
can host configuration created with this Server Template. The boot settings set where the server will
boot from (the server’s boot device).
1. Select an OS Boot Type of FC, Local HD, PXE, SAN (FCoE), SAN (iSCSI), or SD Card.
Depending on the boot type, enter additional information:
• If PXE or SAN (FCoE), select a Virtual Boot NIC to indicate the network from which the operating
system will be loaded.
Note If SAN (iSCSI), select a Virtual Boot NIC to indicate the network from which the operating system
will be loaded.
Note This list is populated with networks added on the Networking Configuration pane from Setup >
Networking.
2. Click Finish.
Limitations on Editing Server Templates and Profiles
If the Server Template has any attached Server Profiles in a non-IDLE state (for example, not running,
configuring, error), then the only change a user or administrator can make is to change the vNIC (Network
Settings -> Edit vNIC). Users can add new networks and modify the Select Network(s) list. Users cannot
change the native VLAN network.
If the Server Template does not have any Server Profiles associated with it, everything on the Server
Template can be modified except the name of the template.
If the Server Template has attached Server Profiles, but all Server Profiles in IDLE state, the following
apply:
• Server Template Settings – Users can change any value except Name.
• BIOS Settings – Users can change any value except for Integrated RAID Controller.
• RAID Settings – Users can change all values except Integrated RAID Controller.
• Firmware Settings – Users can change all values.
• Network Settings – Users can change Bandwidth Oversubscription and Virtual NIC Mapping Order.
Users cannot add or delete NICs. Users can Edit NICs with the stipulations below:
— Edit VNIC – Users can add new networks and can modify the Select Network(s) list. Users cannot
change the Native VLAN network.
• Boot Settings – User cannot change any values.
